▶ EngineEngine Manufacturer Shibaura Simpson Engine Model N4LDI-TA SJV326 Engine Type 4-cylinder turbocharged intercooled diesel, liquid-cooled 3-cylinder, turbocharged, intercooled No. of Cylinders 4 3 Displacement 135.2 in³ 157.9 in³ Rated Engine Speed 2600 rpm 2000 rpm Engine Power (Gross) 53.9 hp 55 hp PTO Power Mech: 41.3 hp; HST: 39.7 hp 45.3 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry Not Published Fuel System Common rail direct injection Electronically controlled high-pressure common rail Alternator Not Published Not Published ▶ HydraulicsPump Type Engine-driven gear-type pump Mark 1A scotch yoke piston pump Implement Flow Not Published Not Published Steering Flow Not Published Not Published Total Hydraulic Flow Not Published 15.7 gpm Overall Hydraulic Pump Flow 12.6 gpm 15.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow 12.1 gpm 10.6 gpm No. of Standard Remote Valves Cab: 1 pair One No. of Optional Remote Valves Up to 3 Not Published ▶ Fluid CapacityFuel Tank Capacity 14 gal 14.5 gal Coolant Capacity 7.08 qt 4 gal Crankcase Capacity 6.87 qt 2.5 gal Transmission / Hydraulic System Capacity Power Shuttle: 10.04 gal; HST: 9.25 gal 10.5 gal Front Axle Fluid Capacity 9 qt Not Published ▶ PTO & HitchPTO Type Independent, with soft-start feature Live PTO Rear 540 rpm (6-spline) 540 rpm, 6-spline Mid-PTO Availability Optional, 2,000 rpm Not Published Category, 3-Point Hitch Category I with extendable ball ends Category I and II Hitch Lift Capacity Not Published 4,519 lb Hitch Lift Capacity (at 24”) 3,086 lb 2,755 lb Lift Control Type Draft control optional Draft, position and response control ▶ Transmission & DrivetrainTransmission Type 12 x 12 power shuttle or 3-range hydrostatic 8F x 2R SideShift sliding gear No. of Speeds 12 x 12 Power Shuttle (3 ranges, 4 gears); HST: 3-range, infinite speeds in each range 8 forward and 2 reverse Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Single stage dry type Not Published Differential Lock & Limited Slip Options Mechanical engagement via right side heel pedal Mechanical engagement via right-side heel pedal ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic steering with separate reservoir Brakes Internal wet disc brakes, independent foot pedals Oil-immersed wet disc Seat Suspension & Adjustability Suspended seat with armrests and seat belts (vinyl on ROPS, cloth on cab), tilt steering ReverseRise adjustable seat with fixed steering column Front Axle Type Cast-steel 4WD front axle, center driveline, bevel-gear final drives Straight adjustable (2WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 65.4 in 66.5 in Wheelbase 77.9 in 80.7 in Ground Clearance 14.8 in Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.4 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.9 in Not Published Overall Length 132.3 in 138 in ▶ WeightTractor Weight (Base) 12x12 Power Shuttle: 3,968 lb (ROPS base weight) 4,894 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options AG, Turf, Industrial, Snow Standard (ag): 6.00x16 front, 13.6x28 rear; optional (ag): 7.5x16 front, 16.6x28 rear R1 Agricultural - Front 9.5x16 6.00x16 (7.5x16 optional) R1 Agricultural - Rear 13.6x28 13.6x28 (16.6x28 optional) R3 Turf - Front 27x10.50-15 Not Published R3 Turf - Rear 44x18.00-20 Not Published R4 Industrial - Front 10-16.5 Not Published R4 Industrial - Rear 17.5L-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System DL135: Skid steer quick attach Skid steer style coupling Loader Model DL135 FLx2815 Loader Lift Height DL135: 111 in (at pivot pin) FLx2815: 111 in; 911X: 114 in Loader Lift Capacity (Full Height) DL135: 2,610 lb (at pivot pin, full height) FLx2815: 2,810 lb (at pivot pin); 911X: 2,470 lb (at pivot pins) Loader Breakout Force DL135: 4,000 lb (at pivot pin) FLx2815: 4,240 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Five-year powertrain warranty 5-year powertrain warranty
