▶ EngineEngine Manufacturer Mitsubishi Yanmar Engine Model S3L2 3TNV88F-EPJT2 Engine Type 3-cylinder diesel Diesel, naturally aspirated, direct injection No. of Cylinders 3 3 Displacement 80.4 in³ 100.2 in³ Rated Engine Speed 2700 rpm 2400 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 18.5 hp 19.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water pump Air Cleaner Single replaceable dry element Dry type with safety element Fuel System Not Published Direct injection Alternator 50 A 55 A, 12 V ▶ HydraulicsPump Type Not Published Implement/steering pump: tandem gear pump; hydrostatic pump: PV axial-piston pump Implement Flow 6.7 gpm 5.3 gpm Steering Flow 2.9 gpm 4.0 gpm Total Hydraulic Flow 9.6 gpm (6.7 + 2.9, computed) 9.3 gpm Overall Hydraulic Pump Flow 9.6 gpm (6.7 + 2.9, computed) 9.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves One (DIA, optional) Up to 2 (optional) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 7.5 gal Coolant Capacity Not Published 5.2 qt Crankcase Capacity Not Published 4.5 qt Transmission / Hydraulic System Capacity Not Published 5.5 gal Front Axle Fluid Capacity Not Published 4 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Not Published PTO Rear 540 rpm 540 rpm Mid-PTO Availability Standard, 2000 rpm Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,433 lb Not Published Hitch Lift Capacity (at 24”) 1,058 lb 1,356 lb Lift Control Type Chain-type stabilizers, fixed link ends Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic (HST), dual pedal Hydrostatic transmission (HST) No. of Speeds HST, 2 ranges Not Published Max Travel Speed (Forward) 11.3 mph (HST, R4 tires) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Open operator station (OOS) Steering Hydrostatic Power steering Brakes Mechanical wet multi-disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Four-wheel drive (standard) 4WD (MFWD) Front Axle Rating Not Published 1,760 lb Drawbar Capacity Not Published 880 lb (maximum vertical load) ▶ Dimensions & ManeuverabilityOverall Width 49.1 in (with R4 tires) 56.9 in (min. rear tread, standard R1 tires); 61.7 in (max. rear tread, larger R4 tires) Wheelbase 59 in 62.8 in Ground Clearance Not Published 12.7 in (R4 tires) Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 85.5 in (with R4 tires) 95.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 103.6 in (with R4 tires) 115.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,708 lb 2,222 lb Weight with ROPS and Loader Not Published 2,972 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 turf tread or R4 industrial tread R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 7-14 R1 Agricultural - Rear Not Published 11.2-24 R3 Turf - Front 23x8.50-12 27X8.50-15 R3 Turf - Rear 33x12-16.5 41X14-20 R4 Industrial - Front 23x8.50-12 25X8.50-14 or 27X8.50-15 R4 Industrial - Rear 12-16.5 15-19.5 or 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Quick-change attachment carrier Loader Model 235TL 300E Loader Lift Height 235TL: 80.7 in (at pivot pin) 84 in (at pivot pin) Loader Lift Capacity (Full Height) 235TL: 1,034 lb 1,186 lb (at pivot pin) Loader Breakout Force 235TL: 1,672 lb 1,704 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years; powertrain 3 years (5 years total) Basic 24 months or 2,000 hours; powertrain 72 months or 2,000 hours
