▶ EngineEngine Manufacturer Mitsubishi Mitsubishi Engine Model S3L2 S3L2 Engine Type 3-cylinder diesel 3-cylinder, indirect injection, water-cooled No. of Cylinders 3 3 Displacement 80.4 in³ 80.4 in³ Rated Engine Speed 2700 rpm 2500 rpm Engine Power (Gross) 24.4 hp 24.4 hp PTO Power 18.5 hp 18.5 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Single replaceable dry element Dry Fuel System Not Published Indirect injection Alternator 50 A 50 A, 12 V ▶ HydraulicsPump Type Not Published Transmission driven Implement Flow 6.7 gpm 5.9 gpm Steering Flow 2.9 gpm 2.6 gpm Total Hydraulic Flow 9.6 gpm (6.7 + 2.9, computed) 8.5 gpm Overall Hydraulic Pump Flow 9.6 gpm (6.7 + 2.9, computed) 8.5 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves 1 (DIA, optional) 1 pair (2 quick couplers, optional) ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity Not Published 1.0 gal Crankcase Capacity Not Published 1.1 gal Transmission / Hydraulic System Capacity Not Published 5.3 gal Front Axle Fluid Capacity Not Published 0.8 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent (electro-hydraulic) PTO Rear 540 rpm Standard (540 rpm) Mid-PTO Availability Standard, 2000 rpm Standard (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,433 lb 1,433 lb Hitch Lift Capacity (at 24”) 1,058 lb 1,058 lb Lift Control Type Chain-type stabilizers, fixed link ends Manual position control ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic (HST), dual pedal Hydrostatic Drive No. of Speeds HST, 2 ranges 2 ranges Max Travel Speed (Forward) 11.3 mph (HST, R4 tires) 11.5 mph Max Travel Speed (Reverse) Not Published 7.2 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal) Mechanical differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Mechanical wet multi-disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Four-wheel drive (standard) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Horizontal load: 3,527 lb; Vertical load: 551 lb pulled / 882 lb pushed ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 103.6 in 103 in Overall Width 49.1 in 44.9 in Wheelbase 59 in 59 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 8.2 ft (with brake applied) Height to Top of ROPS 85.5 in 92.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 1,832 lb 1,609 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 turf tread or R4 industrial tread R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Not Published 23X10.50-12 R1 Agricultural - Rear Not Published 255/75-15.3 R3 Turf - Front 23x8.50-12 23x8.50-12 R3 Turf - Rear 33x12-16.5 33x12.5-16.5 R4 Industrial - Front 23x8.50-12 23x8.50-12 R4 Industrial - Rear 12-16.5 33x12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System Not Published LL2102: Quick-attach front end loader Loader Model 235TL LL2102 Loader Lift Height 235TL: 80.7 in LL2102: 85.7 in (at pivot pin) Loader Lift Capacity (Full Height) 235TL: 1,034 lb LL2102: 1,276 lb (at pivot pin, full height) Loader Breakout Force 235TL: 1,672 lb LL2102: 1,687 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Boomer Guard 5 Limited Warranty: 5 years (2 years bumper-to-bumper plus 3 years powertrain) 6-year limited warranty
