▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3CRV-T4 L3C19-T4 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel 4-stroke, vertical, water cooling, CRDI No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Gear: 34 hp; HST: 32 hp 34.4 hp Engine Emissions Constraints Tier 4B (final) Not Published Cooling System Type Liquid cooled Water-cooled Air Cleaner Replaceable primary and inner elements Dry Fuel System Electronically controlled common rail direct injection Delphi CRDI (Common Rail Direct Injection) Alternator ROPS: 70 A, 12 V; Cab: 85 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear pump type, engine drive Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm 12.3 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 2 pairs No. of Optional Remote Valves Up to 2 (second valve optional) Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 10.5 gal; Cab: 12.4 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity 7.5 qt 2.3 gal Crankcase Capacity 5.8 qt 1.6 gal Transmission / Hydraulic System Capacity 8.5 gal 11.4 gal Front Axle Fluid Capacity 6.87 qt 2.1 gal ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent PTO with wet disk clutch PTO Rear 540 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Standard (2000 rpm) Optional, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 2,756 lb Hitch Lift Capacity (at 24”) 1,345 lb 2,469 lb Lift Control Type Position control (draft control optional) Position and draft control ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal Synchro-shuttle (mechanical) No. of Speeds Gear: 12F/12R; HST: 3-range F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph 16.8 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 13.60 mph 15.3 mph Clutch Gear: dry single disc (9.4 in); HST: n/a Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal) Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic Brakes Wet multi-disc Wet, multi-disc Seat Suspension & Adjustability ROPS: adjustable suspension seat (fore/aft, weight and height adjustment); Cab: cloth seat with weight control, easy fore/aft movement and adjustable armrests Not Published Front Axle Type Four-wheel drive (FWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 66.4 in 62.5 in Wheelbase 66 in 73.2 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 9.2 ft (with brake applied) 9.5 ft (with brake applied) Height to Top of ROPS 92.7 in 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 90 in 88.1 in Overall Length 119 in 133 in (bumper to link) ▶ WeightTractor Weight (Base) ROPS Gear: 2,804 lb; ROPS HST: 2,870 lb; Cab: 3,574 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 7-14 9.5-16 (6PR) R1 Agricultural - Rear 11.2-24 13.6-24 (8PR) R3 Turf - Front 25x8.50-14 28x8.5-15 R3 Turf - Rear 41x14.00-20 41x14-20 R4 Industrial - Front 25x8.50-14 12-16.5 R4 Industrial - Rear 43x16.00-20 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Tool-free loader mount; optional skid-steer quick-attach plates Not Published Loader Model 250TLA LL4104 Loader Lift Height 250TLA: 104 in (at pivot pin) LL4104: 96.3 in Loader Lift Capacity (Full Height) 250TLA: 1,822 lb (at bucket pivot pin, max height) LL4104: 2,713 lb (at pivot pin) Loader Breakout Force 250TLA: 3,257 lb (at bucket pivot pin) LL4104: 3,802 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total) General: 2 years or 750 hours (whichever occurs first). Extended powertrain: 6 years or 1,500 hours (whichever occurs first), for tractors retailed after January 1, 2017
