▶ EngineEngine Manufacturer LS Mtron Iseki Engine Model LS Mtron L3C19-T Iseki E4FH Engine Type Water-cooled, 4-stroke common rail turbocharged diesel 4-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 4 Displacement 114.7 in³ 148.6 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 52.8 hp @ 600 rpm 53.6 hp PTO Power 40 hp 40 hp Engine Emissions Constraints Tier 4B Final Tier 4 Cooling System Type Pressurized liquid w/ recirculating bypass Liquid cooled Air Cleaner Not Published Dry Fuel System High pressure common rail (ECU controlled) Common rail direct injection Alternator 70 A, 12 V Not Published ▶ HydraulicsPump Type Gear Two gear-type pumps for steering and 3-point/remotes Implement Flow 8.5 gpm 12.6 gpm Steering Flow HST: 6.3 gpm; Gear: 4.2 gpm 7 gpm Total Hydraulic Flow HST: 14.8 gpm; Gear: 12.7 gpm 19.6 gpm (12.6 + 7, computed) Overall Hydraulic Pump Flow HST: 14.8 gpm; Gear: 12.7 gpm 19.6 gpm (12.6 + 7, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 11.0 gal 14.0 gal Coolant Capacity 2.3 gal 7.61 qt Crankcase Capacity 5.8 qt 7.82 qt Transmission / Hydraulic System Capacity 11.4 gal 10.04 gal Front Axle Fluid Capacity 2.2 gal 9 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent with SoftStart electronic modulation PTO Rear 540 rpm 540 rpm (1-3/8 in) Mid-PTO Availability Optional Optional, 2,000 rpm Category, 3-Point Hitch Category I Category I and II Hitch Lift Capacity 2,756 lb 3,483 lb Hitch Lift Capacity (at 24”) 2,469 lb 3,086 lb Lift Control Type Position control Not Published ▶ Transmission & DrivetrainTransmission Type HST: 3-range hydrostatic; Gear: 16x16 12x12 power shuttle No. of Speeds HST: 3-range; Gear: 16F/16R 12 forward and 12 reverse Max Travel Speed (Forward) HST: 15.63 mph; Gear: 16.8 mph Not Published Max Travel Speed (Reverse) HST: 11.37 mph; Gear: 15.3 mph Not Published Clutch HST: Not Applicable; Gear: Dry disc Not Published Differential Lock & Limited Slip Options Differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Open station: vinyl-clad seat; standard cab: spring-suspension seat with armrests; deluxe cab: air-ride seat with armrests Front Axle Type 4WD (FWD) Solid cast front axle Front Axle Rating Not Published Not Published Drawbar Capacity Short: 2,317 lb; Regular: 1,598 lb; Extend: 1,091 lb Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 142 in 132.3 in Overall Width 63 in 70.1 in Wheelbase 73 in Not Published Ground Clearance 15 in 14.0 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 96 in 102.4 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 91 in 92.9 in ▶ WeightTractor Weight (Base) Not Published ROPS: 4,035 lb; Cab: 4,420 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 9.5-16 9.5-16 R1 Agricultural - Rear 13.6-24 13.6-28 standard; 16.9-24 optional R3 Turf - Front 28X8.50-15 27x10.50-15 R3 Turf - Rear 41X14.00-20 44x18.00-20 R4 Industrial - Front 12X16.5 10-16.5 R4 Industrial - Rear 17.5LX24 14.9-24; 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System 260TLA: New Holland Quick Mount; optional skid steer quick attach plates FL2814: pin-type or skid steer Loader Model Not Published FL2814 Loader Lift Height 109 in FL2814: 111 in Loader Lift Capacity (Full Height) 2,371 lb FL2814: 2,570 lb Loader Breakout Force 4,081 lb FL2814: 3,910 lb ▶ WarrantyWarranty Length & Coverage 6-year limited powertrain, 2-year full coverage 5-year powertrain warranty
