▶ EngineEngine Manufacturer FPT Industrial AGCO Power Engine Model F5G 33 AWIC Engine Type 4-cylinder diesel, turbocharged and aftercooled 3-cylinder, intercooled turbocharged diesel No. of Cylinders 4 3 Displacement 207 in³ 201 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 99 hp 100 hp PTO Power 85 hp 87 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Not Published Dual element (primary and secondary) Fuel System Electronic high-pressure common rail fuel injection High-pressure common rail direct fuel injection Alternator ROPS: 120 A; Cab: 150 A 80 A ▶ HydraulicsPump Type Open-center; dual pumps (implement pump plus dedicated steering pump) Two-stage pump Implement Flow 16.9 gpm Not Published Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 26.6 gpm Not Published Overall Hydraulic Pump Flow 26.6 gpm Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 17.2 gpm No. of Standard Remote Valves 2 rear remotes (open center with detent) 2 No. of Optional Remote Valves 1 (third rear remote, DIA kit) 1 ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 33 gal Coolant Capacity Not Published 4.2 gal Crankcase Capacity Not Published 3.3 gal Transmission / Hydraulic System Capacity Not Published Power Shuttle: 10.6 to 11.4 gal; Mechanical: 8.5 to 9.2 gal Front Axle Fluid Capacity Not Published Dana: 1.45 gal beam plus 0.24 gal per final drive; Carraro: 1.3 gal beam plus 0.21 gal per final drive ▶ PTO & HitchPTO Type Fully independent hydraulic PTO Independent, electrohydraulic engagement PTO Rear 540 rpm (standard); 540/1000 rpm with interchangeable shafts (optional) 540/540E standard; 540/1000 optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 5,620 lb 4,850 lb Lift Control Type Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) 12x12 fully synchronized power shuttle, 6 gears x 2 ranges, electrohydraulic shuttle lever; optional Dyna-2 24x24 powershift No. of Speeds 12F/12R (standard); 20F/20R with creeper (optional) 12 forward and 12 reverse; 24 forward and 24 reverse with optional Dyna-2 Max Travel Speed (Forward) 27 mph (4WD front axle); 20 mph (2WD front axle) 25 mph Max Travel Speed (Reverse) 27.25 mph (12x12, 4WD front axle, 18R34 tires) Not Published Clutch Not Published Multidisc wet clutch with easy shift knob and electrohydraulic power shuttle lever Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement Hydraulic with electronic control, rear axle engaged via electrohydraulic rocker switch; 4WD front axle Hydra-Lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Cab: tilt and telescopic steering column; Platform: tilt steering column Brakes Hydraulic wet disc Hydraulic multidisc brakes with mechanical parking brake, independently controlled via foot pedals Seat Suspension & Adjustability Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests Cab: mechanical swiveling seat with armrests, air-ride swivel seat optional; Platform: mechanical spring suspension seat with armrests Front Axle Type Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Heavy-duty 2WD or 4WD front axle Front Axle Rating 9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 163.1 in (2WD); 160.9 in (4WD) Not Published Overall Width 75.7 in 60.3 in (minimum, with std. 420/85R30 rear tires) Wheelbase 92.2 in (2WD); 89.9 in (4WD) 88.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 134 in (optional 2WD front axle, w/o brakes) Not Published Height to Top of ROPS 106.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.1 in Not Published ▶ WeightTractor Weight (Base) 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) 2WD ROPS: 7,478 lb; 2WD Cab: 8,294 lb; 4WD ROPS: 7,734 lb; 4WD Cab: 8,644 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions 2WD: 9.5L-15 front, 420/85R34 rear; 4WD: 340/85R24 front, 420/85R34 rear R1 Agricultural - Front 2WD: 10.00-16; 4WD: 12.4-24 2WD: 9.5L-15; 4WD: 340/85R24 R1 Agricultural - Rear 18.4R34 (reference tire for OEM weights and dimensions) 420/85R34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) 931X and 936X: universal skid steer type quick release Loader Model 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) FL.3522, FL.3615, 931X, 936X Loader Lift Height 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in FL.3522: 140 in; FL.3615: 140 in; 931X: 136 in; 936X: 136 in (at pivot pin) Loader Lift Capacity (Full Height) 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb FL.3522: 2,760 lb; FL.3615: 3,420 lb; 931X: 2,140 lb; 936X: 3,340 lb (to full height, at 31.5 in forward of pivot pin) Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
