▶ EngineEngine Manufacturer Fiat Powertrain Technologies (FPT) Doosan Engine Model F36 DL03-LEA07 Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, in-line vertical, water-cooled No. of Cylinders 4 4 Displacement 220 in³ 208 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 108.6 hp 110 hp PTO Power Not Published 92.2 hp Engine Emissions Constraints Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Not Published Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dual air cleaner Fuel System Common rail fuel injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Gear Implement Flow 21.7 gpm Not Published Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 31.5 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 31.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) 1 (third valve) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully-independent, electrohydraulic, wet-clutch Independent PTO Rear 540/1000 rpm (interchangeable) 540 / 1,000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) 8,003 lb Lift Control Type 12x12: mechanical draft control; Dual Command: electronic draft control Position, draft, mixed control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle Synchronized shuttle, power shuttle type No. of Speeds 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) 32F/32R Max Travel Speed (Forward) 25 mph 24.87 mph Max Travel Speed (Reverse) Not Published 24.69 mph Clutch Not Published Wet multi disc Differential Lock & Limited Slip Options Electrohydraulic differential lock Rear differential lock (standard) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Air-suspension cloth seat Fully adjustable suspension swivel seat (deluxe cab) Front Axle Type 4WD heavy-duty, class 1.5 front axle (standard) 4WD, electric/hydraulic engagement Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 88.6 in Wheelbase 92.5 in 93.3 in Ground Clearance Not Published 19.5 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 109 in Overall Length 158.2 in 168.9 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 10,240 lb 9,064 lb (with cab and ag tires; cab is standard) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available R1 Agricultural: 13.6-24 front, 18.4-34 rear R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) Quick attach (QA) bucket, 90 in; dual lever quick attach, built-in parking stand Loader Model 650LU (NSL); 655LU (MSL) KL1153 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) KL1153: 143.3 in (at pivot pin) Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) KL1153: 4,190 lb (at pivot pin) Loader Breakout Force Not Published KL1153: 8,310 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
