▶ EngineEngine Manufacturer Fiat Powertrain Technologies (FPT) FPT Engine Model F36 Not Published Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, turbocharged and aftercooled No. of Cylinders 4 4 Displacement 220 in³ 219.7 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 115.3 hp 117 hp PTO Power Not Published 99 hp Engine Emissions Constraints Stage V Compliant with ECOBlue Compact HI-eSCR + Light CEGR Tier 4 Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System Common rail fuel injection Not Published Alternator Not Published Not Published ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Not Published Implement Flow 21.7 gpm 21.7 gpm Steering Flow 9.7 gpm Not Published Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) Not Published Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 2 No. of Optional Remote Valves 1 (3rd rear remote, optional); 3rd rear remote with 1 diverter (optional) 3 (or 3 with diverter) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 34.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully-independent, electrohydraulic, wet-clutch Not Published PTO Rear 540/1000 rpm (standard, interchangeable) Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with flex link ends Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 4,123 lb (standard); 6,938 lb (with 2 aux rams, optional) 4,123 lb (6,938 lb optional) Lift Control Type 12x12: mechanical draft control; Dual Command: electronic draft control 12x12: mechanical draft control, top link sensing; Hi-Lo: electronic draft control, lower link sensing ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle; 20x20 power shuttle with creeper; 24x24 Dual Command hi-lo power shuttle (all available); column-mounted electronic power shuttle 12x12 electronic power shuttle (standard); 20x20 electronic power shuttle with creeper (optional) No. of Speeds 12x12, 20x20 with creeper, or 24x24 Dual Command (all available) 12F/12R (20F/20R with creeper optional) Max Travel Speed (Forward) 25 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic differential lock Electro-hydraulic differential lock; Class 1.0 MFD front axle with limited slip ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Air-suspension cloth seat Not Published Front Axle Type 4WD heavy-duty, class 1.5 front axle (standard) Class 1.0 MFD with limited slip Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) Not Published Wheelbase 92.5 in 92.5 in (MFD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 106.2 in Overall Length 158.2 in 158.2 in (MFD cab) ▶ WeightTractor Weight (Base) 10,240 lb 10,240 lb (MFD, cab, without ballast) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 rear (reference tire for weight and dimensions); rear tires as large as R38 available Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, 650LU and 655LU) Not Published Loader Model 650LU (NSL); 655LU (MSL) L635 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in (max lift height to pivot pin) L635: up to 149 in Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) Not Published Loader Breakout Force Not Published Not Published ▶ WarrantyWarranty Length & Coverage Not Published Not Published
