▶ EngineEngine Manufacturer FPT KIOTI Engine Model F36 4J243TA-TP5B Engine Type 4-cylinder diesel, turbocharged and aftercooled 4-cylinder, in-line vertical, water-cooled, turbocharged and intercooled CRDI diesel (4J243TA-TP5B) No. of Cylinders 4 4 Displacement 219.7 in³ 233.9 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 88.5 hp 90 hp PTO Power Not Published 70 hp Engine Emissions Constraints Stage V (ECOBlue Compact HI-eSCR + Light CEGR) Not Published Cooling System Type Not Published Water-cooled Air Cleaner Not Published Dry element with evacuator valve Fuel System Common rail fuel injection CRDI Alternator Not Published Not Published ▶ HydraulicsPump Type Open center, dual pumps: implement pump plus dedicated steering pump Gear Implement Flow 21.7 gpm 19.8 gpm Steering Flow 9.7 gpm 12.2 gpm Total Hydraulic Flow 31.4 gpm (21.7 + 9.7, computed) 32 gpm Overall Hydraulic Pump Flow 31.4 gpm (21.7 + 9.7, computed) 32 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (four couplers) 3 No. of Optional Remote Valves 1 (3rd rear remote); 1 with diverter (3rd rear remote with 1 diverter) 4th remote valve ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 47.6 gal Coolant Capacity Not Published 4.6 gal Crankcase Capacity Not Published 3.9 gal Transmission / Hydraulic System Capacity Not Published 20.34 gal Front Axle Fluid Capacity Not Published 2.6 gal ▶ PTO & HitchPTO Type Fully independent electrohydraulic PTO, wet clutch Independent PTO Rear 540/1000 rpm (interchangeable, standard) 540 / 540E / 1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published 8,079 lb Hitch Lift Capacity (at 24”) 4,123 lb 8,002 lb Lift Control Type Electronic draft control (Dual Command); single-lever Lift-O-Matic PLUS (standard) Electronic control ▶ Transmission & DrivetrainTransmission Type 24x24 Dual Command hi-lo power shuttle, column-mounted Power Shuttle w/ Hi-Lo Shift No. of Speeds 24F/24R (Dual Command) 24 forward / 24 reverse Max Travel Speed (Forward) 25 mph 23.83 mph Max Travel Speed (Reverse) Not Published 23.67 mph Clutch Not Published Wet Multi Disc Differential Lock & Limited Slip Options Electrohydraulic rear differential lock Mechanical rear differential lock (standard); front limited-slip differential ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Hydrostatic Power Steering Brakes Not Published Wet Disc Seat Suspension & Adjustability Air-suspension cloth seat Heated air suspension seat, 20 degree swivel both directions, adjustable fore/aft Front Axle Type Heavy-duty class 1.5 4WD front axle 4WD, outboard planetary drives, limited-slip differential Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Max. Drawbar vertical load: 3,307 lb; Max. Trailer loading weight: 9,921 lb ▶ Dimensions & ManeuverabilityOverall Width 56.9 in min to 84.8 in max (front wheels); 56.1 in min to 84.2 in max (rear wheels) 88.6 in Wheelbase 92.5 in 94.9 in Ground Clearance Not Published 18.9 in Min. Turn Radius without Brakes Not Published 12.7 ft (with brake applied) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 103.6 in 111.9 in Overall Length 158.2 in 170.8 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 10,240 lb 10,230 lb (with AG tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 420/85R38 (reference tire for weight and dimensions); rear tires as large as R38 available R1 Agricultural (bias 13.6-24 / 18.4-34, radial 13.6R-24 / 18.4R-34); R14 radial (340/85R24 / 460/85R34) R1 Agricultural - Front Not Published 13.6-24 R1 Agricultural - Rear Not Published 18.4-34 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (available, both LU loaders) KL1155: quick-attach system with built-in parking stand; single-lever joystick control with float; bucket level indicator Loader Model 650LU (NSL); 655LU (MSL) KL1155 Loader Lift Height 650LU: 149.7 in; 655LU: 149.7 in KL1155: 150.6 in (to pivot pin) Loader Lift Capacity (Full Height) 650LU: 3,578 lb; 655LU: 4,625 lb (at 31.5 in from pivot point) KL1155: 4,216 lb (at pivot pins) Loader Breakout Force Not Published KL1155: 8,554 lb (at pivot pins) ▶ WarrantyWarranty Length & Coverage Not Published Non-commercial: basic 24 months, unlimited hours, parts and labor, 0% deductible; powertrain 48 months, unlimited hours, HX series
