▶ EngineEngine Manufacturer FPT Industrial Mahindra Engine Model F5G Not Published Engine Type 4-cylinder diesel, turbocharged and aftercooled Four-stroke, turbocharged, direct injection, water cooled diesel No. of Cylinders 4 4 Displacement 207 in³ 215.4 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 86 hp 91.5 hp PTO Power 73 hp 75 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Not Published Fuel System Electronic high-pressure common rail fuel injection Common rail direct injection Alternator ROPS: 120 A; Cab: 150 A 140 A ▶ HydraulicsPump Type Open-center; dual pumps (implement pump plus dedicated steering pump) Not Published Implement Flow 16.9 gpm 17 gpm Steering Flow 9.7 gpm 5.2 gpm Total Hydraulic Flow 26.6 gpm 22.2 gpm Overall Hydraulic Pump Flow 26.6 gpm 22.2 gpm Hydraulic System Type Open center Open center with position and draft control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 rear remotes (open center with detent) 2 No. of Optional Remote Valves 1 (third rear remote, DIA kit) 1 ▶ Fluid CapacityFuel Tank Capacity 30.3 gal 25.9 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Fully independent hydraulic PTO 2-speed independent single lever PTO PTO Rear 540 rpm (standard); 540/1000 rpm with interchangeable shafts (optional) 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II CAT II with telescoping stabilizers & flex links Hitch Lift Capacity Not Published 5500 lb (measuring point not stated by Mahindra) Hitch Lift Capacity (at 24”) 5,620 lb Not Published Lift Control Type Mechanical draft control; Lift-O-Matic PLUS single-lever raise/lower (standard) Position and draft control ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle, column-mounted (standard); 20x20 power shuttle with creeper (optional) Full synchro mesh with forward/reverse power shuttle & constant mesh range No. of Speeds 12F/12R (standard); 20F/20R with creeper (optional) 12F / 12R Max Travel Speed (Forward) 27 mph (4WD front axle); 20 mph (2WD front axle) Not Published Max Travel Speed (Reverse) 27.25 mph (12x12, 4WD front axle, 18R34 tires) Not Published Clutch Not Published Power shuttle with torsional damper (wet) Differential Lock & Limited Slip Options Mechanical rear differential lock (pedal); limited-slip 4WD front axle with electrohydraulic engagement Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Steel frame Steering Power steering Power steering Brakes Hydraulic wet disc Oil immersed brakes, 7-in disc diameter, mechanically actuated Seat Suspension & Adjustability Cab: air-suspension cloth seat with armrests, 10° swivel (standard); ROPS: vinyl mechanical-suspension seat with armrests mComfort seat with integrated foldable armrests, recline feature and standard air suspension Front Axle Type Limited-slip 4WD front axle with electrohydraulic engagement (standard); heavy-duty 2WD front axle (optional) Not Published Front Axle Rating 9,480 lb (standard limited-slip 4WD front axle, maximum capacity); 10,360 lb (optional heavy-duty 4WD front axle); 7,716 lb (optional 2WD heavy-duty front axle) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 163.1 in (2WD); 160.9 in (4WD) 176.6 in Overall Width 75.7 in 83 in Wheelbase 92.2 in (2WD); 89.9 in (4WD) 95.6 in Ground Clearance Not Published 14.1 in Min. Turn Radius without Brakes 134 in (optional 2WD front axle, w/o brakes) 15.5 ft Height to Top of ROPS 106.5 in Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 102.1 in 111.2 in ▶ WeightTractor Weight (Base) 6,988 lb (ROPS/2WD); 7,672 lb (ROPS/4WD); 7,473 lb (cab/2WD); 8,157 lb (cab/4WD) 8587 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 2WD: 10.00-16 front, 18.4-30 rear; 4WD: 12.4-24 front, 18.4-30 rear (standard); 18.4R34 rear is the reference tire for weights and dimensions Not Published R1 Agricultural - Front 2WD: 10.00-16; 4WD: 12.4-24 12.4 x 24 R1 Agricultural - Rear 18.4R34 (reference tire for OEM weights and dimensions) 18.4 x 30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or Euro-style quick attach faceplate (optional, all four LU loaders) Skid steer style quick attach Loader Model 710LU (NSL); 715LU (MSL); 720LU (NSL); 725LU (MSL) 8100CL Loader Lift Height 710LU: 126.3 in; 715LU: 125.9 in; 720LU: 134 in; 725LU: 135 in 8100CL: 139 in Loader Lift Capacity (Full Height) 710LU: 3,461 lb; 715LU: 3,573 lb; 720LU: 3,849 lb; 725LU: 4,204 lb 8100CL: 4,200 lb Loader Breakout Force 710LU: 3,739 lb; 715LU: 3,860 lb; 720LU: 4,455 lb; 725LU: 5,661 lb (31.5 in forward of the bucket pivot point) 8100CL: 6,050 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
