▶ EngineEngine Manufacturer FPT FPT Engine Model F5D Not Published Engine Type 4-cylinder diesel 4-cylinder diesel, electronic high-pressure common rail No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 106 hp 105 hp PTO Power 91 hp 91 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Electronic high-pressure common rail Alternator 120 A 120 A ▶ HydraulicsPump Type Gear pumps Not Published Implement Flow T5.105: 16.1 gpm (21.1 gpm optional); T5.105 Electro Command: 21.1 gpm (16.1 gpm optional) 17.2 gpm (22.2 gpm optional) Steering Flow T5.105: 10.0 gpm (11.4 gpm optional); T5.105 Electro Command: 11.4 gpm (10.0 gpm optional) 10 gpm (11.4 gpm optional) Total Hydraulic Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 27.2 gpm (17.2 + 10, computed) Overall Hydraulic Pump Flow T5.105: 26.1 gpm (16.1 + 10.0, computed); T5.105 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 27.2 gpm (17.2 + 10, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 2 No. of Optional Remote Valves Not Published 3 ▶ Fluid CapacityFuel Tank Capacity 37 gal 37 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic clutch Independent PTO Rear 540/1000 Not Published Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) T5.105: 6,393 lb (10,452 lb with 2 optional rams); T5.105 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 6,393 lb Lift Control Type Electronic draft control Electronic draft control (EDC) with rear fender switch ▶ Transmission & DrivetrainTransmission Type T5.105: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.105 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) Not Published No. of Speeds T5.105: 12F/12R (20F/20R or 24F/24R optional); T5.105 Electro Command: 16F/16R (32F/32R optional) 12F/12R (20F/20R or 24F/24R optional) Max Travel Speed (Forward) Not Published Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Wet disc, electro-hydraulic power shuttle Differential Lock & Limited Slip Options Electro-hydraulic rear differential lock; limited slip front Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Hydraulic wet disc Seat Suspension & Adjustability Numerous seat options including a premium low-frequency heated air-suspension seat; full-size instructor seat available Heated air suspension seat with 15-degree swivel (optional) Front Axle Type Heavy-duty 4WD front axle (standard) MFD (four-wheel drive) Front Axle Rating 4,500 lb (in-action capacity at 4 mph) Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch T5.105: 163.8 in; T5.105 Electro Command: 165.0 in 164 in (16.9R-34 rear tires) Overall Width 82.6 in 75 in (minimum) Wheelbase 92.5 in 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.105: 105.4 in; T5.105 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 103 in (16.9R-34 rear tires) ▶ WeightTractor Weight (Base) T5.105: 9,370 lb; T5.105 Electro Command: 9,700 lb 9,370 lb (cab, MFD, 16.9R-34 rear tires) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published R1 agricultural; 16.9R-34 rear reference tire; 38 in rear tires available R1 Agricultural - Front Not Published 14.9R24 R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Quick-Latch loader mounting with Quick-Attach faceplate Loader Model 825TL; 835TL (each NSL or MSL) L735 (NSL or MSL); L745 (NSL or MSL) Loader Lift Height 825TL: 138 in; 835TL: 146 in L735: 135 in (11 ft 3 in); L745: 146.75 in (12 ft 2.75 in) Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb L735: 2,844 lb (NSL) / 2,954 lb (MSL); L745: 3,616 lb (NSL) / 3,814 lb (MSL) (at 31.5 in forward of pivot pin, max height) Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb L735: 2,976 lb (NSL) / 3,285 lb (MSL); L745: 3,858 lb (NSL) / 4,254 lb (MSL) (boom breakout at 31.5 in) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
