▶ EngineEngine Manufacturer FPT FPT Industrial Engine Model F5D F5G Engine Type 4-cylinder diesel 4-cylinder diesel No. of Cylinders 4 4 Displacement 207 in³ 207 in³ Rated Engine Speed 2300 rpm 2300 rpm Engine Power (Gross) 114 hp 117 hp PTO Power 98 hp 99 hp Engine Emissions Constraints Tier 4A Tier 4B Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Electronic high-pressure common rail fuel injection Alternator 120 A Not Published ▶ HydraulicsPump Type Gear pumps Open-center tandem gear pumps: implement pump plus steering and services pump Implement Flow T5.115: 16.1 gpm (21.1 gpm optional); T5.115 Electro Command: 21.1 gpm (16.1 gpm optional) 16.9 gpm Steering Flow T5.115: 10.0 gpm (11.4 gpm optional); T5.115 Electro Command: 11.4 gpm (10.0 gpm optional) 9.7 gpm Total Hydraulic Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 26.6 gpm Overall Hydraulic Pump Flow T5.115: 26.1 gpm (16.1 + 10.0, computed); T5.115 Electro Command: 32.5 gpm (21.1 + 11.4, computed) 26.6 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 (3 optional) 2 or 3 (base) No. of Optional Remote Valves Not Published Third rear remote (dealer-installed) ▶ Fluid CapacityFuel Tank Capacity 37 gal 30.3 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Hydraulic Hydraulic PTO with power shuttle transmissions; lever-engaged PTO with mechanical shuttle PTO Rear 540/1000 540/540E (12x12 base); 540/1000 (12x12 optional); 540/540E (24x24 Dual Command base); 540/1000 (24x24 Dual Command optional) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II (flexible link ends) Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) T5.115: 6,393 lb (10,452 lb with 2 optional rams); T5.115 Electro Command: 6,393 lb (8,809 lb with 1 optional ram, 10,452 lb with 2) 5,620 lb (7,351 lb with optional auxiliary lift ram) Lift Control Type Electronic draft control 12x12: rear hitch control levers; Dual Command cab: Electronic Draft Control (EDC) mouse and fender switches; single-lever Lift-O-Matic Plus (optional on 12x12, standard on Dual Command ROPS) ▶ Transmission & DrivetrainTransmission Type T5.115: 12x12 power shuttle (standard), 20x20 power shuttle with creeper or 24x24 Dual Command power shuttle (optional); T5.115 Electro Command: 16x16 power shuttle (standard), 32x32 power shuttle with creeper (optional) 12x12 mechanical shuttle (standard); 12x12 power shuttle, 20x20 power shuttle with creeper, 24x24 Dual Command Hi-Lo powershift with electrohydraulic power shuttle, or 40x40 Dual Command with creeper (optional) No. of Speeds T5.115: 12F/12R (20F/20R or 24F/24R optional); T5.115 Electro Command: 16F/16R (32F/32R optional) 12F/12R (standard); 20F/20R, 24F/24R or 40F/40R (optional) Max Travel Speed (Forward) Not Published 20 mph (12x12 and 20x20 creeper, standard; 25 mph transport option); 25 mph (24x24 and 40x40 Dual Command) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Electrohydraulic differential lock (optional) Mechanical rear differential lock, pedal (12x12 models); electrohydraulic rear differential lock, rocker switch (Dual Command models) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Seat options include a low-frequency heated air-suspension seat; full-size instructor seat available Cab: fabric mechanical-suspension seat or fabric air-suspension seat with swivel; full-size instructor seat available. ROPS: vinyl mechanical-suspension seat with armrests Front Axle Type Heavy-duty 4WD front axle (standard) Standard-duty, electronically engaged 4WD front axle; optional: standard-duty mechanically engaged 4WD, heavy-duty electronically engaged 4WD, or heavy-duty 2WD front axle Front Axle Rating 4,500 lb (in-action capacity at 4 mph) 9,479 lb (standard-duty 4WD, in-action capacity at 4 mph); 10,361 lb (heavy-duty 4WD, in-action capacity at 4 mph) Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 82.6 in 75.7 in Wheelbase 92.5 in 92.2 in (2WD); 89.9 in (4WD) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published 134 in (2WD heavy-duty front axle) Height to Top of ROPS Not Published 106.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model T5.115: 105.4 in; T5.115 Electro Command: 105.6 in (non-suspended cab), 107.2 in (suspended cab) 102.1 in Overall Length T5.115: 163.8 in; T5.115 Electro Command: 165.0 in 163.1 in (2WD); 160.9 in (4WD) ▶ WeightTractor Weight (Base) T5.115: 9,370 lb; T5.115 Electro Command: 9,700 lb 6,988 lb (2WD ROPS); 7,672 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Ag: 11.2-24 front, 16.9-30 rear; 13.6-24 front, 16.9-34 rear; 12.4-24 front, 18.4-30 rear; 14.9-24 front, 18.4-34 rear; Turf: 13.6-16.1 front, 16.9-24 rear; Industrial: 12.5/80-18 front, 19.5L24 rear R1 Agricultural - Front Not Published 4WD: 11.2-24, 13.6-24, 12.4-24 or 14.9-24 (paired with 16.9-30, 16.9-34, 18.4-30 or 18.4-34 rears) R1 Agricultural - Rear Not Published 16.9-30, 16.9-34, 18.4-30 or 18.4-34 R3 Turf - Front Not Published 13.6-16.1 R3 Turf - Rear Not Published 16.9-24 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L24 ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer-style or European-style Skid-steer-style or Euro-style quick attach faceplate Loader Model 825TL; 835TL (each NSL or MSL) Factory-fit: 655TL (NSL or MSL), 665TL (NSL or MSL); field-fit: 632TL (NSL), 637TL (MSL) Loader Lift Height 825TL: 138 in; 835TL: 146 in 655TL NSL: 126 in; 655TL MSL: 125 in; 665TL NSL: 134 in; 665TL MSL: 135 in; 632TL: 134 in; 637TL: 134 in Loader Lift Capacity (Full Height) 825TL NSL: 2,843 lb; 825TL MSL: 2,954 lb; 835TL NSL: 3,483 lb; 835TL MSL: 3,681 lb 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 665TL NSL: 2,632 lb; 665TL MSL: 3,428 lb (at 31.5 in from pivot point); 632TL: 2,028 lb; 637TL: 3,175 lb (to max height, 31.5 in from pivot point) Loader Breakout Force 825TL NSL: 2,976 lb; 825TL MSL: 3,284 lb; 835TL NSL: 3,725 lb; 835TL MSL: 4,100 lb 655TL NSL: 3,739 lb; 655TL MSL: 3,860 lb; 665TL NSL: 4,455 lb; 665TL MSL: 5,661 lb (at 31.5 in from bucket pivot point); 632TL: 3,351 lb; 637TL: 3,461 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
