Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Up to 4 rear remote valves (deluxe, with diverter); up to 3 mid-mount valves
Up to 4 total (ISO couplers, rear)
Fuel Tank Capacity
47.5 gal
46.2 gal
Coolant Capacity
Not Published
5.3 gal
Crankcase Capacity
Not Published
4.5 gal
Transmission / Hydraulic System Capacity
Not Published
15.8 gal (PowrQuad Plus/AutoQuad Plus)
Front Axle Fluid Capacity
Not Published
2-piece front axle (types 730/733/735): axle housing 1.69 gal (suspended axle) or 1.43 gal (axle without suspension); final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 1 (type 740 M40): axle housing 1.90 gal; final drive per side 0.21 gal (without brake), 0.37 gal (with brake). 3-piece front axle version 2 (types 730/733/735): axle housing 1.7 gal; final drive per side 0.21 gal (without brake), 0.47 gal (with brake)
PTO Type
Fully independent direct-drive PTO with electro-hydraulic wet clutch and Soft Start
Electro-hydraulically operated, oil cooled, multi-disc; standard 1.5 in 540/1000 reversible shaft
PTO Rear
540/1000 rpm (540 at 1969, 540E at 1546, 1000 at 1893 engine rpm)
Terralock Auto Diff and Auto 4WD (standard); electro-hydraulic front and rear differential lock
Not Published
Frame Type
Not Published
Full frame design
Steering
Power steering
Power steering
Brakes
Hydraulic wet disc
Hydraulic wet disc brakes
Seat Suspension & Adjustability
Comfort seat, low-frequency suspension, cloth (standard); Dynamic Comfort or Auto Comfort seats with heating and active ventilation (optional); instructor seat optional
Economy seat with mechanical suspension standard; standard seat with air suspension optional
Front Axle Type
Class 1.75 heavy-duty 4WD front axle (standard); Terraglide front axle suspension (optional)
MFWD standard; 2WD optional; Triple Link Suspension (TLS) MFWD available (hydro-pneumatic, self-levelling, 3.9 in range), also with brakes
Front Axle Rating
Not Published
9,655 lb maximum permissible front axle load, MFWD, normal operation up to 25 mph
176.6 in (basic 242.5 lb front weight, cab + MFWD, to draft link in horizontal position)
Overall Width
74 in (narrow); 90 in (standard)
100.4 in (maximum width for road travel)
Wheelbase
98 in
94.5 in
Ground Clearance
Not Published
Front-wheel drive axle: 11.3-25.1 in depending on front tire SRI; differential housing with drawbar: 13.7-23.5 in depending on rear tire SRI (cab + MFWD)
Min. Turn Radius without Brakes
182 in (4WD / Terraglide suspended front axle; brake use not stated)
14 ft (4.36 m) (6110M & 6120M)
Height to Top of ROPS
Not Published
105.2-115.0 in depending on rear tire SRI (ground to extended ROPS, without beacon light, open operator's station)
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
106 in (low-profile roof, 540/65R34 tires)
105.4-115.3 in depending on rear tire SRI (ground to cab roof, without beacon light)
