▶ EngineEngine Manufacturer FPT Industrial Mahindra Engine Model FPT NEF4 Not Published Engine Type 4-cylinder diesel 4-cylinder, liquid-cooled inline diesel No. of Cylinders 4 4 Displacement 273 in³ 215.6 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 130 hp 125 hp PTO Power 111 hp 106 hp Engine Emissions Constraints Stage V Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Not Published Fuel System Not Published Common Rail Diesel Technology (mCRD) Alternator Standard: 120 A, 12 V; Optional: 200 A, 12 V Not Published ▶ HydraulicsPump Type Closed-center load-sensing pump plus separate steering and services pump Not Published Implement Flow 21.1 gpm 21.2 gpm Steering Flow 9.6 gpm 9.25 gpm Total Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Closed center load sensing (CCLS) Open center, position and draft control, telescoping stabilizers and flex links Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (9125 S); 3 (9125 P) No. of Optional Remote Valves Up to 4 rear remote valves (with diverter); up to 3 mid-mount valves One (3rd outlet on S models; 4th outlet on P model) ▶ Fluid CapacityFuel Tank Capacity 47.5 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Direct-drive PTO with push-pull engagement and Soft Start Independent PTO Rear 540/540E/1000 rpm (540 at 1969, 540E at 1546, 1000 at 1893 engine rpm) 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II Category II with telescopic link ends Hitch Lift Capacity 12,125 lb (at ball ends) Not Published Hitch Lift Capacity (at 24”) 10,228 lb 5,787 lb (9125 S); 7,628 lb (9125 P) Lift Control Type Electronic draft control (EDC) Electronic draft control with fender switches ▶ Transmission & DrivetrainTransmission Type Dynamic Command: 24x24 dual-clutch 8-step semi-powershift; Auto Command: continuously variable transmission (CVT) Power shuttle with synchromesh No. of Speeds Dynamic Command: 24F/24R; Auto Command: continuously variable 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Max Travel Speed (Forward) Dynamic Command: 25 mph; Auto Command: 25 mph (31 mph optional) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Terralock automatic differential lock and automatic 4WD (standard) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Hydraulic wet disc Wet disc Seat Suspension & Adjustability Standard: low-frequency suspension seat, cloth; optional: heated seat with active ventilation; instructor seat optional Seat with adjustable air-suspension, folding adjustable armrest, recline and adjustable headrest Front Axle Type Class 1.75 heavy-duty 4WD front axle (standard); Terraglide suspension (optional) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 74 in (narrow); 90 in (standard) 91.3 in Wheelbase 98 in Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes 182 in (4WD, Terraglide suspended front axle; brake use not stated) Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 106 in (low-profile roof, 540/65R34 tires) 107 in Overall Length 173 in (max, weight carrier to rear linkage) 169.3 in ▶ WeightTractor Weight (Base) Not Published 9,385 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published Not Published R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Not Published Skid steer style quick attach couplers Loader Model 800TL Series (wide frame) 9125L Loader Lift Height Not Published 162 in Loader Lift Capacity (Full Height) Not Published 5,415 lb (at pivot pin) Loader Breakout Force Not Published 6,874 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
