▶ EngineEngine Manufacturer FPT John Deere Engine Model NEF PowerTech 4045 EWL Engine Type 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail Diesel, turbocharged with intercooler, 4-valve HPCR No. of Cylinders 4 4 Displacement 274 in³ 276 in³ Rated Engine Speed 2200 rpm 2200 rpm Engine Power (Gross) 130 hp 130 hp PTO Power 112 hp 115 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Not Published Air Cleaner Not Published Dry type air cleaner with safety (secondary) element Fuel System High-pressure common rail fuel injection High Pressure Common Rail (HPCR) electronic fuel injection, 4-valve Alternator 120 A 120 A, 12 V ▶ HydraulicsPump Type Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Tandem gear pump Implement Flow 19 gpm (combined implement and auxiliary pump flow) 18.4 gpm Steering Flow 9 gpm 6.3 gpm Total Hydraulic Flow 28 gpm 25.6 gpm Overall Hydraulic Pump Flow 28 gpm 25.6 gpm Hydraulic System Type Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (rear); 2 (mid) No. of Optional Remote Valves Not Published Up to 3 total (rear); up to 3 total (mid) ▶ Fluid CapacityFuel Tank Capacity 57.5 gal 42.4 gal (Standard Cab) Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent rear PTO, electro-hydraulic clutch PTO Rear 540/1000 rpm 540 rpm standard; 540/1000 rpm optional Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (flex link ends) Category II (convertible to I) Hitch Lift Capacity 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two 6,975 lb standard; 7,868 lb optional Hitch Lift Capacity (at 24”) Not Published 6,975 lb standard; 7,868 lb optional Lift Control Type Not Published Electrohydraulic ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional PowrQuad PLUS 16F/16R or Powr8 32F/16R (cab only) No. of Speeds 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) 16F/16R (PowrQuad PLUS); 32F/16R (Powr8) Max Travel Speed (Forward) 19 mph or 25 mph (25 mph 4WD only) 24.9 mph; PowrQuad PLUS 16F/16R (standard) or Powr8 32F/16R (optional) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Electro-hydraulic Differential Lock & Limited Slip Options Not Published Electro-hydraulic rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cast iron mid-frame design Steering Not Published Power steering Brakes Not Published Hydraulic wet disk brakes, self-equalizing and self-adjusting Seat Suspension & Adjustability Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Mechanical suspension seat standard; air suspension seat optional; premium air suspension seat (heated, low-frequency) optional Front Axle Type Heavy-duty front axle, 2WD or 4WD (both optional, cab only) MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published 3,197 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights) Not Published Overall Width Not Published Not Published Wheelbase Not Published 92.5 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 110.2 in Not Published ▶ WeightTractor Weight (Base) 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle); 9,921 lb (2WD, cab) 9,185 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4-38 R1 rear with 14.9-28 R1 front (4WD) or 10.00-16 front (2WD) R1 Agricultural R1 Agricultural - Front 14.9-28 (4WD); 10.00-16 (2WD) 12.4R24 R1 Agricultural - Rear 18.4-38 18.4R30 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published 12.5/80-18 in, 12PR R4 Bias R4 Industrial - Rear Not Published 19.5L-24 in, 10PR R4 Bias ▶ Loader & AttachmentsQuick Attach Loader System Skid steer (SSL) or Euro style attachment couplers Not Published Loader Model 4WD: 830LA (NSL), 835LA (MSL); 2WD: 810LA (NSL) 520M (4WD only); 540M; 540R; 600M Loader Lift Height 830LA: 150.0 in; 835LA: 150.0 in; 810LA (2WD): 144.0 in (to pivot pin) 520M: NSL/MSL 130-132 in; 540M: NSL 137-141 in, MSL 138-141 in; 540R: 141.85 in; 600M: NSL 148.8-152.8 in, MSL 148-153 in Loader Lift Capacity (Full Height) 830LA: 2,557 lb; 835LA: 3,813 lb; 810LA (2WD): 2,094 lb (to maximum height, measured 31.5 in forward of the pivot pin) 520M (4WD): NSL 3,334.9-3,611.6 lb, MSL 2,460.1-2,661 lb; 540M: NSL 2,394-2,666 lb, MSL 3,117.3-3,309.1 lb; 540R: 3,406 lb; 600M: NSL 3,104-3,236 lb, MSL 3,891-4,085 lb Loader Breakout Force 830LA: 3,681 lb; 835LA: 3,968 lb; 810LA (2WD): 3,020 lb (measured 31.5 in forward of the pivot pin) Not Published ▶ WarrantyWarranty Length & Coverage Not Published 24 Months or 2000 Hours, Whichever Comes First (whole-machine, standard Agricultural Equipment tractor term)
