▶ EngineEngine Manufacturer FPT Mahindra Engine Model NEF Not Published Engine Type 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail 4-cylinder, liquid-cooled inline diesel No. of Cylinders 4 4 Displacement 274 in³ 215.6 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 130 hp 125 hp PTO Power 112 hp 106 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Not Published Fuel System High-pressure common rail fuel injection Common rail direct injection Alternator 120 A Not Published ▶ HydraulicsPump Type Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Not Published Implement Flow 19 gpm (combined implement and auxiliary pump flow) 21.2 gpm Steering Flow 9 gpm 9.25 gpm Total Hydraulic Flow 28 gpm Not Published Overall Hydraulic Pump Flow 28 gpm Not Published Hydraulic System Type Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Open center with position & draft control, telescoping stabilizers & flex links Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 (9125 S); 3 (9125 P) No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 57.5 gal Not Published Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent PTO Rear 540/1000 rpm 540 @ 2220 rpm, 1000 @ 2227 rpm (9125 S); 540 @ 2220 rpm, 750 @ 2208 rpm, 1000 @ 2227 rpm (9125 P) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (flex link ends) Category II with telescopic link ends Hitch Lift Capacity 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Not Published Hitch Lift Capacity (at 24”) Not Published 5,787 lb (9125 S); 7,628 lb (9125 P) Lift Control Type Not Published Electronic draft control with fender switches ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional Power shuttle with synchromesh No. of Speeds 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) 12F / 12R (9125 S); 24F / 24R + 8 creepers (9125 P) Max Travel Speed (Forward) 19 mph or 25 mph (25 mph 4WD only) Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Power steering Brakes Not Published Wet disc Seat Suspension & Adjustability Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) mComfort seat with adjustable air ride suspension, foldable adjustable armrest, recline and adjustable headrest Front Axle Type Heavy-duty front axle, 2WD or 4WD (both optional, cab only) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights) 169.3 in Overall Width Not Published 90.9 in Wheelbase Not Published Not Published Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 110.2 in 107 in ▶ WeightTractor Weight (Base) 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle); 9,921 lb (2WD, cab) 9,385 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4-38 R1 rear with 14.9-28 R1 front (4WD) or 10.00-16 front (2WD) Not Published R1 Agricultural - Front 14.9-28 (4WD); 10.00-16 (2WD) Not Published R1 Agricultural - Rear 18.4-38 Not Published R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer (SSL) or Euro style attachment couplers Skid steer style quick attach couplers Loader Model 4WD: 830LA (NSL), 835LA (MSL); 2WD: 810LA (NSL) 9125L Loader Lift Height 830LA: 150.0 in; 835LA: 150.0 in; 810LA (2WD): 144.0 in (to pivot pin) 9125L: 162 in Loader Lift Capacity (Full Height) 830LA: 2,557 lb; 835LA: 3,813 lb; 810LA (2WD): 2,094 lb (to maximum height, measured 31.5 in forward of the pivot pin) 9125L: 5,415 lb Loader Breakout Force 830LA: 3,681 lb; 835LA: 3,968 lb; 810LA (2WD): 3,020 lb (measured 31.5 in forward of the pivot pin) 9125L: 6,874 lb ▶ WarrantyWarranty Length & Coverage Not Published Not Published
