▶ EngineEngine Manufacturer FPT FPT Engine Model NEF NEF Engine Type 4-cylinder, 16-valve, turbocharged and intercooled, common-rail diesel 4-cylinder, 16-valve, turbocharged and intercooled, common-rail diesel, electronic fuel delivery control No. of Cylinders 4 4 Displacement 274 in³ 274 in³ Rated Engine Speed 2200 rpm 2100 rpm Engine Power (Gross) 130 hp 125 hp PTO Power 112 hp 105 hp Engine Emissions Constraints Tier 4B/Final Stage V/Final Cooling System Type Not Published Not Published Air Cleaner Not Published Not Published Fuel System High-pressure common rail fuel injection High-pressure common-rail, electronic fuel delivery control Alternator 120 A 150 A ▶ HydraulicsPump Type Fixed-displacement pumps for steering, implement and auxiliary circuits, with a combining/diverter valve Electro Command: fixed-displacement gear pump (CCLS optional); Dynamic Command, Auto Command: closed-center load-sensing (CCLS) pump Implement Flow 13 gpm (implement pump); 9 gpm auxiliary pump standard on Plus, optional on Value Value: 21.1 gpm; Plus, Elite: 29.9 gpm Steering Flow 7 gpm 12.4 gpm (17.2 gpm optional pump with Class 4 front axle) Total Hydraulic Flow 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Overall Hydraulic Pump Flow 29 gpm (with the 9 gpm auxiliary pump: standard on Plus, optional on Value) Value: 33.5 gpm (21.1 + 12.4, computed); Plus, Elite: 42.3 gpm (29.9 + 12.4, computed) Hydraulic System Type Fixed-displacement pumps with combining/diverter valve; closed-center rear remote valves with flow control Electro Command: fixed displacement, closed-center (CCLS optional); Dynamic Command: closed-center load-sensing (CCLS); Auto Command: CCLS Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 mechanical (Value, Plus, Elite) No. of Optional Remote Valves Not Published Rear: 3 or 4 mechanical, or 3 or 4 electro-hydraulic (Elite); mid-mount: 2 or 3, mechanical or electronic ▶ Fluid CapacityFuel Tank Capacity 57.5 gal 52.2 gal (58.6 gal with auxiliary tank); Dynamic Command: 60 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Not Published Independent, direct-drive PTO with push-pull engagement and Soft Start; reversible PTO shaft PTO Rear 540/1000 rpm 540/1000 rpm (540 at 1969 engine rpm, 1000 at 1893 engine rpm) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II (flex link ends) Not Published Hitch Lift Capacity 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Not Published Hitch Lift Capacity (at 24”) Not Published Value: 8,338 lb; Auto Command: 9,214 lb; Plus, Elite and Auto Command with optional larger rams: 11,649 lb Lift Control Type Not Published Electronic draft control ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional Electro Command: 16x16 semi-powershift (standard), with 17x16 economy, 17x16 31 mph, 32x32 creeper and auto-shift options; Dynamic Command: 23x23 semi-powershift, with 24x24 economy, 31 mph and creeper options No. of Speeds 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Electro Command: 16F/16R, or 17F/16R economy or high-speed, 32F/32R with creeper; Dynamic Command: 23F/23R, or 24F/24R optional Max Travel Speed (Forward) 19 mph or 25 mph (25 mph 4WD only) 25 mph (Electro Command 16x16 and Dynamic Command 23x23 standard); 31 mph (17x16 high-speed and Dynamic Command 24x24 31 mph options, FWD only); 19 mph (2WD) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Terralock automatic traction management: automatic four-wheel drive engagement and front and rear differential locks ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Not Published Not Published Brakes Not Published Not Published Seat Suspension & Adjustability Mechanical-suspension seat standard; air-suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Standard: low-frequency suspension seat; optional: heated low-frequency suspension seat, or heated and ventilated active-suspension seat; swiveling backrest; suspended cab optional Front Axle Type Heavy-duty front axle (standard); 2WD (cab only) or 4WD Standard FWD axle (Class 3 and 4); optional: Terraglide suspended FWD axle or SuperSteer FWD axle; heavy-duty 2WD axle available on Electro Command Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width Not Published 89.8 in (minimum; 91 in with 650/65R38 tires) Wheelbase Not Published Standard FWD axle: 104 in; Terraglide suspended axle: 105.7 in; SuperSteer axle: 109.8 in; 2WD: 96 in Ground Clearance Not Published 18.8 in (18.4R38, 520/70R38 or 600/65R38 rear tires; 16.8 in with 16.9R38, 20.8 in with 650/65R38) Min. Turn Radius without Brakes Not Published 15.1 ft (standard FWD axle, 55 degree turn angle); 14.1 ft (2WD or SuperSteer axle, 65 degree turn angle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 110.2 in 115.2 in (standard cab, 18.4R38 tires); 110.4 in (low profile cab); 117.7 in (suspended cab) Overall Length 184.7 in (4WD, with front weights); 184.5 in (2WD, with front weights) 204.3 in (front linkage to rear linkage) ▶ WeightTractor Weight (Base) 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle); 9,921 lb (2WD, cab) 10,560 lb (minimum shipping weight, cab FWD, less ballast) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options 18.4-38 R1 rear with 14.9-28 R1 front (4WD) or 10.00-16 front (2WD) Rear: 16.9R38, 18.4R38, 520/70R38, 600/65R38, 650/65R38 (suspended cab only), 480/70R38, 540/65R38 or 650/60R38 with matching front tires R1 Agricultural - Front 14.9-28 (4WD); 10.00-16 (2WD) Not Published R1 Agricultural - Rear 18.4-38 18.4R38 (reference tire; also 16.9R38, 520/70R38, 600/65R38, 650/65R38, 480/70R38, 540/65R38, 650/60R38) R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front Not Published Not Published R4 Industrial - Rear Not Published Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid steer (SSL) or Euro style attachment couplers Euro style (850LA, 855LA, 857LA); Euro or skid steer style (810LA) Loader Model 4WD: 830LA (NSL), 835LA (MSL); 2WD: 810LA (NSL) FWD: 850LA (NSL), 855LA (MSL); SuperSteer FWD: 857LA (MSL); 2WD: 810LA (NSL) Loader Lift Height 830LA: 150.0 in; 835LA: 150.0 in; 810LA (2WD): 144.0 in (to pivot pin) 850LA: 13.5 ft; 855LA: 13.5 ft; 857LA: 13.9 ft; 810LA (2WD): 11.9 ft (to pivot pin, base equipment tires) Loader Lift Capacity (Full Height) 830LA: 2,557 lb; 835LA: 3,813 lb; 810LA (2WD): 2,094 lb (to maximum height, measured 31.5 in forward of the pivot pin) 850LA: 2,932 lb; 855LA: 5,202 lb; 857LA: 4,365 lb; 810LA (2WD): 2,380 lb (to maximum height, measured 31.5 in forward of the pivot pin, with rear counterbalance) Loader Breakout Force 830LA: 3,681 lb; 835LA: 3,968 lb; 810LA (2WD): 3,020 lb (measured 31.5 in forward of the pivot pin) 850LA: 4,673 lb; 855LA: 5,974 lb; 857LA: 4,894 lb; 810LA (2WD): 3,439 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
