▶ EngineEngine Manufacturer FPT FPT Engine Model F5 NEF Engine Type Turbocharged 4-cylinder diesel 4-cylinder, 16-valve, turbocharged, air-to-air intercooled diesel with high-pressure common rail No. of Cylinders 4 4 Displacement 207 in³ 274 in³ Rated Engine Speed 2300 rpm 2200 rpm Engine Power (Gross) 112 hp 110 hp PTO Power 92 hp 92 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Not Published Air Cleaner Not Published Not Published Fuel System Not Published High-pressure common rail fuel injection Alternator 120 A 120 A ▶ HydraulicsPump Type Not Published Fixed displacement pumps (steering, implement, auxiliary) with combining/diverter valve Implement Flow 16.9 gpm (21.6 gpm optional) 19 gpm (combined implement and auxiliary pump flow) Steering Flow 9.7 gpm 9 gpm Total Hydraulic Flow 26.6 gpm (16.9 + 9.7, computed) 28 gpm Overall Hydraulic Pump Flow 26.6 gpm (16.9 + 9.7, computed) 28 gpm Hydraulic System Type Open center Fixed displacement pumps with combining/diverter valve; deluxe closed-center rear remote valves with flow control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 or 3 Not Published No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity ROPS: 24 gal; Cab: 29 gal 57.5 gal Coolant Capacity Not Published Not Published Crankcase Capacity Not Published Not Published Transmission / Hydraulic System Capacity Not Published Not Published Front Axle Fluid Capacity Not Published Not Published ▶ PTO & HitchPTO Type Wet clutch PTO with electro-hydraulic engagement Not Published PTO Rear 540 (base); 540/540E or 540/1000 (optional) 540/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category II (flex link ends) Hitch Lift Capacity Not Published 3,735 lb (ASAE); 5,499 lb with one optional auxiliary lift cylinder; 7,326 lb with two Hitch Lift Capacity (at 24”) 3,200 lb (6,200 lb with optional ram) Not Published Lift Control Type Lift-O-Matic 3-point quick raise system Not Published ▶ Transmission & DrivetrainTransmission Type 12x12 power shuttle 8x8 synchronized power shuttle (hydraulic, left-hand) standard; 16x8 Dual Power synchronized hydraulic shuttle with Hi-Lo (premium); 10:1 creeper optional No. of Speeds 12F/12R 8F/8R (base); 16F/8R (premium Dual Power with Hi-Lo) Max Travel Speed (Forward) Not Published 19 mph or 25 mph (25 mph 4WD only) Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Not Published Brakes Wet disc Not Published Seat Suspension & Adjustability Cab: cloth air-suspension seat with fold-back instructor seat; ROPS: vinyl air-suspension seat Mechanical suspension seat standard; deluxe air suspension seat with swivel and full-size cushioned instructor seat optional (VisionView cab) Front Axle Type 4WD front axle, electro-hydraulic engagement (standard) 4WD heavy-duty front axle, Standard Duty Class 3 (cab and 4WD only) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 161.1 in (4WD) 184.7 in (4WD, with front weights) Overall Width Not Published Not Published Wheelbase Cab: 88.9 in; ROPS: 83.7 in 99.2 in (4WD, Standard Duty Class 3 axle) Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 103.0 in Not Published Height to Top of ROPS (folded) Low-Profile ROPS: 68.4 in to ROPS pivot (500/60-22.5 R1 tires); 71.9 in (19.5L24 R4 tires) Not Published Height to Top of Cab Model 105.4 in 110.2 in ▶ WeightTractor Weight (Base) Cab/4WD: 8,367 lb; ROPS/4WD: 7,738 lb 11,200 lb (shipping, 4WD, cab, flange axle); 12,192 lb (4WD, cab, bar axle) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf or R4 industrial 18.4-38 R1 rear with 14.9-28 R1 front (4WD) R1 Agricultural - Front 12.4x24 (with 18.4x30 rear); 11.2-24 (with 16.9-30 rear); 11.5/80-18 (with 500/60-22.5 low-profile rear) 14.9-28 (4WD) R1 Agricultural - Rear 18.4x30 (standard); 16.9-30 or 500/60-22.5 low-profile (optional) 18.4-38 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 Not Published R4 Industrial - Rear 19.5L24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System Skid-steer style (84 in bucket standard); Euro-style quick attach available Skid steer (SSL) or Euro style attachment couplers Loader Model 632TL (NSL); 637TL (MSL) 830LA (NSL); 835LA (MSL) Loader Lift Height 632TL: 134.5 in; 637TL: 134.5 in 830LA: 150.0 in; 835LA: 150.0 in (to pivot pin) Loader Lift Capacity (Full Height) 632TL: 2,028 lb; 637TL: 3,174 lb (at 31.5 in from bucket pivot pin to max height) 830LA: 2,557 lb; 835LA: 3,813 lb (to maximum height, measured 31.5 in forward of the pivot pin) Loader Breakout Force Not Published 830LA: 3,681 lb; 835LA: 3,968 lb (measured 31.5 in forward of the pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
