▶ EngineEngine Manufacturer Yanmar Shibaura Engine Model 3TNV80F N843 Engine Type 3-cylinder, naturally aspirated, liquid-cooled diesel 3-cylinder naturally aspirated diesel No. of Cylinders 3 3 Displacement 77.3 in³ 91.3 in³ Rated Engine Speed 3000 rpm 2600 rpm Engine Power (Gross) 24.7 hp 30 hp PTO Power 17.2 hp Gear: 25.5 hp; Hydrostatic: 24 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner Single-element dry air cleaner Not Published Fuel System In-line injection pump, indirect injection (swirl chamber) Not Published Alternator 40 A, 12 V Not Published ▶ HydraulicsPump Type Gear Gear Implement Flow 4.6 gpm 6.2 gpm Steering Flow 2.1 gpm 3.8 gpm Total Hydraulic Flow 6.7 gpm 10.0 gpm (6.2 + 3.8, computed) Overall Hydraulic Pump Flow 6.7 gpm 10.0 gpm (6.2 + 3.8, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 7.1 gal Coolant Capacity 3.49 qt Not Published Crankcase Capacity 3 qt Not Published Transmission / Hydraulic System Capacity 3.3 gal Not Published Front Axle Fluid Capacity 0.5 gal Not Published ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Live (FWD); transmission-driven (2WD gear) PTO Rear 540 rpm Gear 2WD: transmission-driven 540 rpm; Gear FWD: live 540 rpm; Hydrostatic FWD: live 540 rpm Mid-PTO Availability Standard (2,500 rpm) Optional on gear transmission: 2WD gear transmission-driven with overrunning clutch, 2000 rpm; FWD gear and hydrostatic: live, 2000 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 992 lb Not Published Hitch Lift Capacity (at 24”) 728 lb 1,635 lb Lift Control Type Lift-hold-lower Not Published ▶ Transmission & DrivetrainTransmission Type 2-range hydrostatic, dual pedal Gear: 9x3; Hydrostatic: 3-range (FWD only) No. of Speeds Infinite (2 ranges) Gear: 9F/3R; Hydrostatic: 3 ranges Max Travel Speed (Forward) 9.1 mph Gear: 12.9 mph (R1 tires), 12.1 mph (R4 tires); Hydrostatic: 14.5 mph (R1 tires), 13.6 mph (R4 tires) Max Travel Speed (Reverse) 5.5 mph Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Mechanical, foot-operated rear differential lock Mechanical rear differential lock (heel pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet, multi-disc Wet disc Seat Suspension & Adjustability Deluxe high-back seat with armrests and adjustable backrest Padded contoured seat on an inclined track Front Axle Type 4WD FWD (standard); 2WD (optional) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 97.4 in 108.9 in (2WD, ag tires); 111.4 in (FWD, R4 tires); both 3-point raised Overall Width 46.7 in 54.3 in (minimum, ag tires); 62 in (R4 tires) Wheelbase 56.1 in 63.0 in Ground Clearance 12 in Not Published Min. Turn Radius without Brakes 94 in Not Published Height to Top of ROPS 90 in 82.3 in (R4 tires) Height to Top of ROPS (folded) 64 in Not Published Height to Top of Cab Model 87.4 in Not Published ▶ WeightTractor Weight (Base) ROPS: 1,444 lb; Cab: 1,805 lb 2,193 lb (2WD, ag tires, 9x3 gear); 2,385 lb (FWD, R4 tires, 9x3 gear) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial R1 Ag 7.4x14 / 11.2x24; R3 Turf 24x8.50-14 / 13.6x16; R4 Industrial 25x8.50-14 / 15x19.5 R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published 11.2x24 R3 Turf - Front 18x8.50-10 24x8.50-14 R3 Turf - Rear 26x12.0-12 13.6x16 R4 Industrial - Front 18x8.50-10 25x8.50-14 R4 Industrial - Rear 26x12.0-12 15x19.5 ▶ Loader & AttachmentsQuick Attach Loader System 100LC: Quick Mount system, no tools needed Not Published Loader Model 100LC 7308 Loader Lift Height 100LC: 72 in 7308: 100.5 in Loader Lift Capacity (Full Height) 100LC: 1,005 lb 7308: 875 lb Loader Breakout Force 100LC: 2,078 lb 7308: 1,602 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Not Published
