▶ EngineEngine Manufacturer LS Mtron LS Mtron Engine Model L3C19-T4 L3CRV-T5 Engine Type 3-cylinder, turbocharged, liquid-cooled diesel 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 114.7 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 35 hp PTO Power Gear: 34 hp; HST: 32 hp Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Pressurized liquid with recirculating bypass Liquid cooled Air Cleaner Dual element dry air cleaner (primary and inner safety element) Replaceable primary and inner elements Fuel System High pressure common rail, ECU-controlled timing Electronically controlled common rail direct injection Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Gear Gear Implement Flow 8.2 gpm 8.2 gpm Steering Flow Gear: 4.2 gpm; HST: 5.3 gpm Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow Gear: 12.4 gpm; HST: 13.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Gear: 12.4 gpm; HST: 13.5 gpm Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves 1 or 2 Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.5 gal Coolant Capacity 7.5 qt 7.5 qt Crankcase Capacity 5.8 qt 5.8 qt Transmission / Hydraulic System Capacity 8.5 gal 8.5 gal Front Axle Fluid Capacity 6.9 qt 6.87 qt ▶ PTO & HitchPTO Type Independent, electro-hydraulic engagement Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability HST: Standard; Gear: Optional (2,000 rpm) Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,808 lb 1,808 lb Hitch Lift Capacity (at 24”) 1,433 lb 1,345 lb Lift Control Type Position control Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Gear: 12x12 synchronized shuttle; HST: 3-range hydrostatic, dual pedal Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds Gear: 12F/12R; HST: Infinite (3 ranges) Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) Gear: 14.2 mph; HST: 14.8 mph Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) Gear: 13.63 mph; HST: 14.96 mph Gear: 13.63 mph; HST: 13.60 mph Clutch Gear: 9.4 in single dry disc; HST: Not applicable Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Mechanical rear differential lock Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Mechanical suspension seat, fore/aft adjustable, tilting Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type 4WD Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 121 in 119 in Overall Width 66.5 in 66.4 in Wheelbase 67.5 in 66 in Ground Clearance 13 in Not Published Min. Turn Radius without Brakes 123 in (left turn); 124 in (right turn) 9.2 ft (with brake applied) Height to Top of ROPS 87.7 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,067 lb Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 7-14 7-14 R1 Agricultural - Rear 11.2-24 11.2-24 R3 Turf - Front 25x8.50-14 25x8.50-14 R3 Turf - Rear 41x14.00-20 41x14.00-20 R4 Industrial - Front 25x8.50-14 25x8.50-14 R4 Industrial - Rear 43x16-20 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System 140TL: tool-free quick-mount system; optional skid-steer quick-attach plates Tool-free loader mount; optional skid-steer quick-attach plates Loader Model 140TL 250TLA Loader Lift Height 140TL: 91.5 in 250TLA: 104 in Loader Lift Capacity (Full Height) 140TL: 1,500 lb 250TLA: 1,822 lb Loader Breakout Force 140TL: 2,700 lb 250TLA: 3,257 lb ▶ WarrantyWarranty Length & Coverage Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total Basic 2 years or 750 hours; powertrain 4 more years (6 years or 1,500 hours total)
