▶ EngineEngine Manufacturer FPT John Deere Engine Model R753 3029D Engine Type Turbocharged, intercooled 3-cylinder diesel 3-cylinder, naturally aspirated, direct injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 136 in³ 179 in³ Rated Engine Speed 2600 rpm 2400 rpm Engine Power (Gross) 53 hp 53 hp PTO Power 45 hp 45 hp Engine Emissions Constraints Tier 4 Not Published Cooling System Type Pressurized liquid with recirculating bypass Liquid-cooled Air Cleaner 2-stage Dry type with safety element Fuel System Common rail direct injection (CRDI) Direct injection, rotary injection pump, electric shutoff Alternator 75 A 40 A ▶ HydraulicsPump Type Two engine-driven gear pumps, open center, fixed displacement Tandem gear pump Implement Flow 12 gpm 11.4 gpm Steering Flow 5.5 gpm 6.8 gpm Total Hydraulic Flow 17.5 gpm 18.2 gpm Overall Hydraulic Pump Flow 17.5 gpm 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm No. of Standard Remote Valves 1 Not Published No. of Optional Remote Valves 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 17.2 gal 18 gal (open station); 23 gal (cab) Coolant Capacity 10.6 qt 10 qt Crankcase Capacity 6.7 qt 9 qt Transmission / Hydraulic System Capacity ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Front Axle Fluid Capacity 4WD: 8.0 qt 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) ▶ PTO & HitchPTO Type Independent Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch PTO Rear 540 rpm (540/540E optional) 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category II/I Category I and II Hitch Lift Capacity 3,307 lb Not Published Hitch Lift Capacity (at 24”) 2,701 lb 3,374 lb Lift Control Type Position control with mechanical draft control Position and depth control, top link draft sensing ▶ Transmission & DrivetrainTransmission Type 8x8 synchronized shuttle CollarShift standard; SyncShuttle optional; PowrReverser optional No. of Speeds 8F/8R 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) Max Travel Speed (Reverse) 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) Clutch Dry, 11 in organic plate (LUK) Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Differential Lock & Limited Slip Options Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS; cab optional; two-wheel drive or MFWD Steering Power steering Hydrostatic power steering Brakes Individual mechanically actuated wet disc Wet disk, self-equalizing, self-adjusting Seat Suspension & Adjustability Deluxe contoured suspension seat, adjusts to operator height Not Published Front Axle Type 4WD: limited-slip front axle with front differential lock, mechanical engagement Two-wheel drive or mechanical front wheel drive (MFWD) Front Axle Rating Not Published 2720 to 4,700 lb (2WD, by front tire, no loader); 2760 to 4,620 lb (MFWD, by front tire, without loader) Drawbar Capacity Not Published 1,675 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in 122.6 in (2WD); 125.9 in (MFWD) (less drawbar and front weights) (without 3-point hitch) Overall Width ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in 65.4 in Wheelbase ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in 80.7 in Ground Clearance ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in 19.5 in (2WD front axle); 13.4 in (MFWD front axle); 15.8 in (2WD drawbar); 14.9 in (MFWD drawbar) Min. Turn Radius without Brakes ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Height to Top of ROPS ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in 87.8 in Height to Top of ROPS (folded) ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in 74.6 in Height to Top of Cab Model Not Published 97 in ▶ WeightTractor Weight (Base) ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb 4,250 lb (2WD); 4,650 lb (MFWD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural, R3 turf, R4 industrial Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R1 Agricultural - Front ROPS 2WD: 7.5x16, 6 ply; ROPS 4WD: 8.3x24, 6 ply 6.5-16 (2WD); 8.3-24 (MFWD) R1 Agricultural - Rear 13.6x28 R1, 6 ply 13.6-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5x18 Not Published R4 Industrial - Rear 18.4x24 R4 Not Published ▶ Loader & AttachmentsQuick Attach Loader System 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) Not Published Loader Model 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) 521; 541; 541 self-leveling Loader Lift Height 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in 521: 122 in; 541: 126 in; 541 self-leveling: 130 in Loader Lift Capacity (Full Height) 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) Loader Breakout Force 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
