| Engine Manufacturer | John Deere | FPT |
|---|
| Engine Model | 3029D | R753 |
|---|
| Engine Type | 3-cylinder liquid-cooled diesel, naturally aspirated, direct injection | Turbocharged, intercooled 3-cylinder diesel |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 179 in³ | 136 in³ |
|---|
| Rated Engine Speed | 2400 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 53 hp | 53 hp |
|---|
| PTO Power | 45 hp | 45 hp |
|---|
| Engine Emissions Constraints | Not Published | Tier 4 |
|---|
| Cooling System Type | Liquid-cooled | Pressurized liquid with recirculating bypass |
|---|
| Air Cleaner | Dry type with safety element | 2-stage |
|---|
| Fuel System | Direct injection, rotary injection pump with electric shutoff | Common rail direct injection (CRDI) |
|---|
| Alternator | 40 A | 75 A |
|---|
|
|---|
| Pump Type | Tandem gear pump | Dual engine-driven gear pumps, open center, fixed displacement |
|---|
| Implement Flow | 11.4 gpm | 12 gpm |
|---|
| Steering Flow | 6.8 gpm | 5.5 gpm |
|---|
| Total Hydraulic Flow | 18.2 gpm | 17.5 gpm |
|---|
| Overall Hydraulic Pump Flow | 18.2 gpm | 17.5 gpm |
|---|
| Hydraulic System Type | Open center | Open center |
|---|
| Rear Remote Hydraulic Flow | 11.4 gpm | Not Published |
|---|
| No. of Standard Remote Valves | Not Published | 1 |
|---|
| No. of Optional Remote Valves | Not Published | 2 |
|---|
|
|---|
| Fuel Tank Capacity | 18 gal (open station); 23 gal (cab) | 17.2 gal |
|---|
| Coolant Capacity | 10 qt | 10.6 qt |
|---|
| Crankcase Capacity | 9 qt | 6.7 qt |
|---|
| Transmission / Hydraulic System Capacity | 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) | ROPS 2WD: 6.1 gal; ROPS 4WD: 6.6 gal |
|---|
| Front Axle Fluid Capacity | 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) | 4WD: 8.0 qt |
|---|
|
|---|
| PTO Type | Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever operated clutch | Independent |
|---|
| PTO Rear | 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) | 540 rpm (540/540E optional) |
|---|
| Mid-PTO Availability | Not Published | Not Published |
|---|
| Category, 3-Point Hitch | Category I and II | Category II/I |
|---|
| Hitch Lift Capacity | Not Published | 3,307 lb |
|---|
| Hitch Lift Capacity (at 24”) | 3374 lb | 2,701 lb |
|---|
| Lift Control Type | Position and depth control, top link draft sensing | Position control with mechanical draft control |
|---|
|
|---|
| Transmission Type | CollarShift standard; SyncShuttle optional; PowrReverser optional | 8x8 synchronized shuttle |
|---|
| No. of Speeds | 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) | 8F/8R |
|---|
| Max Travel Speed (Forward) | 14.98 mph (CollarShift and SyncShuttle, gear C-3); 14.89 mph (PowrReverser, gear C-4) | 19.1 mph (13.6x28 rear tires); 19.8 mph (14.9x28 rear tires) |
|---|
| Max Travel Speed (Reverse) | 12.78 mph (CollarShift and SyncShuttle, gear C-R); 17.21 mph (PowrReverser, gear C-4 reverse) | 20.2 mph (13.6x28 rear tires); 20.9 mph (14.9x28 rear tires) |
|---|
| Clutch | Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) | Dry, 11 in organic plate (LUK) |
|---|
| Differential Lock & Limited Slip Options | Not Published | Mechanical rear differential lock (foot pedal); 4WD front axle with limited slip and front differential lock |
|---|
|
|---|
| Frame Type | Two-post ROPS; cab optional; two-wheel drive or MFWD | Not Published |
|---|
| Steering | Hydrostatic power steering | Power steering |
|---|
| Brakes | Wet disk, self-equalizing, self-adjusting | Individual mechanically actuated wet disc |
|---|
| Seat Suspension & Adjustability | Not Published | Deluxe contoured suspension seat, adjusts to operator height |
|---|
| Front Axle Type | Two-wheel drive or mechanical front wheel drive (MFWD) | 4WD: limited-slip front axle with front differential lock, mechanical FWD engagement |
|---|
| Front Axle Rating | 2720 to 4700 lb (2WD, by front tire, no loader); 2760 to 4620 lb (MFWD, by front tire, without loader) | Not Published |
|---|
| Drawbar Capacity | 1675 lb | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 122.6 in (2WD); 125.9 in (MFWD) (w/o 3P, less hitch, drawbar and front weights) (without 3-point hitch) | ROPS 2WD: 129.5 in; ROPS 4WD: 134.0 in |
|---|
| Overall Width | 65.4 in | ROPS 2WD: 66.5 in; ROPS 4WD: 67.5 in |
|---|
| Wheelbase | 80.7 in | ROPS 2WD: 77.6 in; ROPS 4WD: 77.2 in |
|---|
| Ground Clearance | 19.5 in (2WD front axle); 13.4 in (MFWD front axle); 15.8 in (2WD drawbar); 14.9 in (MFWD drawbar) | ROPS 2WD: 19.5 in; ROPS 4WD: 15.9 in |
|---|
| Min. Turn Radius without Brakes | 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) | ROPS 2WD: 122.0 in; ROPS 4WD: 190.9 in |
|---|
| Height to Top of ROPS | 87.8 in | ROPS 2WD: 96.5 in; ROPS 4WD: 97.6 in |
|---|
| Height to Top of ROPS (folded) | 74.6 in | ROPS 2WD: 75.9 in; ROPS 4WD: 77.0 in |
|---|
| Height to Top of Cab Model | 97 in | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | 4250 lb (2WD); 4650 lb (MFWD); add approximately 1000 lb with cab | ROPS 2WD: 4,442 lb; ROPS 4WD: 5,059 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 | R1 agricultural, R3 turf, R4 industrial |
|---|
| R1 Agricultural - Front | 6.5-16 (2WD); 8.3-24 (MFWD) | ROPS 2WD: 7.5x16, 6 ply; ROPS 4WD: 8.3x24, 6 ply |
|---|
| R1 Agricultural - Rear | 13.6-28 | 13.6x28 R1, 6 ply |
|---|
| R3 Turf - Front | Not Published | Not Published |
|---|
| R3 Turf - Rear | Not Published | Not Published |
|---|
| R4 Industrial - Front | Not Published | 12.5x18 |
|---|
| R4 Industrial - Rear | Not Published | 18.4x24 R4 |
|---|
|
|---|
| Quick Attach Loader System | Not Published | 600TL Series quick-attach loader (611TL, 621TL, 616TL, 626TL) |
|---|
| Loader Model | 521; 541; 541 self-leveling | 611TL, 616TL, 621TL, 626TL (611TL and 621TL non self-leveling; 616TL and 626TL mechanical self-leveling) |
|---|
| Loader Lift Height | 521: 122 in; 541: 126 in; 541 self-leveling: 130 in | 611TL: 112 in; 616TL: 115 in; 621TL: 119 in; 626TL: 122 in |
|---|
| Loader Lift Capacity (Full Height) | 521: 2500 lb; 541: 2500 lb; 541 self-leveling: 2800 lb (full at pin) | 616TL: 1,940 lb; 621TL: 3,549 lb; 626TL: 2,447 lb (at the pivot pin, full height) |
|---|
| Loader Breakout Force | 521: 3485 lbf; 541: 3484 lbf; 541 self-leveling: 4125 lbf (at pin) | 611TL: 2,998 lb; 616TL: 3,130 lb; 621TL: 3,086 lb; 626TL: 3,527 lb (at 31.5 in ahead of pivot pin) |
|---|
|
|---|
| Warranty Length & Coverage | Not Published | Not Published |
|---|
