▶ EngineEngine Manufacturer FPT John Deere Engine Model S8000 3029T Engine Type Turbocharged 3-cylinder diesel 3-cylinder, turbocharged, direct injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 179 in³ 179 in³ Rated Engine Speed 2300 rpm 2400 rpm Engine Power (Gross) 64 hp 64 hp PTO Power 50 hp 55 hp Engine Emissions Constraints Tier 4B Not Published Cooling System Type Not Published Liquid-cooled Air Cleaner PowerCore dry air cleaner Dry type with safety element Fuel System Bosch electronic high-pressure common rail Direct injection, rotary injection pump, electric shutoff Alternator 120 A 40 A ▶ HydraulicsPump Type Dual gear pumps Tandem gear pump Implement Flow 12.6 gpm 11.4 gpm Steering Flow 7.6 gpm 6.8 gpm Total Hydraulic Flow 20.2 gpm 18.2 gpm Overall Hydraulic Pump Flow 20.2 gpm 18.2 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published 11.4 gpm No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 1 Not Published ▶ Fluid CapacityFuel Tank Capacity 21.7 gal 18 gal (open station); 23 gal (cab) Coolant Capacity Not Published 10 qt Crankcase Capacity Not Published 9 qt Transmission / Hydraulic System Capacity Not Published 10 gal (CollarShift and SyncShuttle, dry clutch); 11.5 gal (PowrReverser, wet clutch) Front Axle Fluid Capacity Not Published 5.2 qt (MFWD axle housing); 0.6 qt (each wheel hub); 5.7 qt (MFWD assembly) ▶ PTO & HitchPTO Type Fully independent, hydraulic wet clutch Fully independent 540 rpm PTO; shiftable 540/540E with SyncShuttle transmission; lever-operated clutch PTO Rear 540 rpm (540/540E optional) 540 rpm (at 2400 engine rpm); 540E (at 1700 engine rpm, SyncShuttle) Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I/II Category I and II Hitch Lift Capacity Not Published Not Published Hitch Lift Capacity (at 24”) 3,500 lb 3,374 lb Lift Control Type Mechanical draft control with upper-link draft sensing; Lift-O-Matic rear hitch control Position and depth control, top link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 hydraulic power shuttle CollarShift standard; SyncShuttle optional; PowrReverser optional No. of Speeds 12F/12R 9 forward, 3 reverse (CollarShift and SyncShuttle); 12 forward, 12 reverse (PowrReverser) Max Travel Speed (Forward) 25 mph 15.62 mph (CollarShift and SyncShuttle, gear C-3); 15.52 mph (PowrReverser, gear C-4) Max Travel Speed (Reverse) Not Published 13.33 mph (CollarShift and SyncShuttle, gear C-R); 17.95 mph (PowrReverser, gear C-4 reverse) Clutch 11 in single dry disc Dual dry clutch (CollarShift and SyncShuttle); multi-disk wet clutch (PowrReverser) Differential Lock & Limited Slip Options Mechanically engaged rear differential lock; limited-slip 4WD front axle with electro-hydraulic push-button engagement Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Two-post ROPS; cab optional; two-wheel drive or MFWD Steering Hydrostatic power steering Hydrostatic power steering Brakes Hydraulic-assist wet brakes Wet disk, self-equalizing, self-adjusting Seat Suspension & Adjustability Cloth air-suspension seat with fold-back instructor seat Not Published Front Axle Type 4WD (MFD) limited-slip front axle, electro-hydraulic engagement Two-wheel drive or mechanical front wheel drive (MFWD) Front Axle Rating 6,500 lb dynamic capacity 2720 to 4,700 lb (2WD, by front tire, no loader); 2760 to 4,620 lb (MFWD, by front tire, without loader) Drawbar Capacity Not Published 1,675 lb ▶ Dimensions & ManeuverabilityOverall Width Not Published 66.7 in Wheelbase 83.6 in 80.7 in Ground Clearance Not Published 18.1 in (2WD front axle); 14.8 in (MFWD front axle); 15.8 in (2WD drawbar); 16.3 in (MFWD drawbar) Min. Turn Radius without Brakes Not Published 11.3 ft (2WD); 12.5 ft (MFWD engaged); 11.3 ft (MFWD disengaged) Height to Top of ROPS Not Published 88.7 in Height to Top of ROPS (folded) Not Published 75.5 in Height to Top of Cab Model 100.2 in 97.9 in Overall Length 154.1 in n/a Overall Length with 3-Point Hitch n/a 123.6 in (2WD); 128.1 in (MFWD) (less drawbar and front weights) (without 3-point hitch) ▶ WeightTractor Weight (Base) Not Published 4,350 lb (2WD); 4,750 lb (MFWD) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 agricultural (11.2x24 / 16.9x30 standard, R1W radials optional), R4 industrial (12.5/80-18 / 19.5L-24) Front: 6.50-16, 7.50-16, 9.5L-15, 27/9.5L-15, 11L-15 (2WD); 9.5L-16, 8.3-24, 9.5-24, 10.5/80-18, 11.2-24 (MFWD). Rear: 13.6-28, 14.9-24, 14.9-28, 16.9-24, 16.9-28, 16.9-30, 18.4-16.1 R1 Agricultural - Front 11.2x24 R1, 6 ply 7.50-16 (2WD); 9.5-24 (MFWD) R1 Agricultural - Rear 16.9x30 R1, 6 ply 14.9-28 R3 Turf - Front Not Published Not Published R3 Turf - Rear Not Published Not Published R4 Industrial - Front 12.5/80-18 R4, 10 ply Not Published R4 Industrial - Rear 19.5L-24 R4, 10 ply Not Published ▶ Loader & AttachmentsQuick Attach Loader System 72 in bucket with SSL (skid steer) or Euro-style quick attach Not Published Loader Model 550LU (non self-leveling); 555LU (mechanical self-leveling) 521; 541; 541 self-leveling Loader Lift Height 550LU: 131.3 in; 555LU: 130.0 in (at pivot pin) 521: 122 in; 541: 126 in; 541 self-leveling: 130 in Loader Lift Capacity (Full Height) Not Published 521: 2,500 lb; 541: 2,500 lb; 541 self-leveling: 2,800 lb (full at pin) Loader Breakout Force Not Published 521: 3,485 lbf; 541: 3,484 lbf; 541 self-leveling: 4,125 lbf (at pin) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
