▶ EngineEngine Manufacturer FPT John Deere Engine Model F36 John Deere PowerTech 4.5L diesel Engine Type 4-cylinder 4-cylinder, turbocharged and intercooled diesel, 4-valve high pressure common rail No. of Cylinders 4 4 Displacement Not Published 276 in³ Rated Engine Speed Not Published 2200 rpm Engine Power (Gross) 90 hp 90 hp PTO Power 75 hp 75 hp @ 100 rpm Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Liquid-cooled Air Cleaner Not Published Dry type with safety element Fuel System Not Published High pressure common rail, 4 valve, electronic fuel control Alternator Not Published 200 A ▶ HydraulicsPump Type Not Published Tandem gear pump (open center); variable axial-piston implement pump (PFC, optional) Implement Flow Not Published 19.3 gpm (open center); 30.9 gpm (PFC) Steering Flow Not Published 6.3 gpm (open center) Total Hydraulic Flow 26.6 gpm 25.6 gpm (open center) Overall Hydraulic Pump Flow Not Published 25.6 gpm (open center); 30.9 gpm (PFC) Hydraulic System Type Not Published Open center (standard); closed center PFC (optional) Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 2 rear and 2 mid (stackable) No. of Optional Remote Valves Not Published Rear: 3 (mechanical or proportional EH, optional; 4th rear by conversion kit); Mid: 3 Deluxe (mechanical or EH, optional) ▶ Fluid CapacityFuel Tank Capacity 34.3 gal 38 gal Coolant Capacity Not Published 4.25 gal Crankcase Capacity Not Published 3.1 gal Transmission / Hydraulic System Capacity Not Published 11.75 gal (open center); 12.5 gal (closed center PFC) Front Axle Fluid Capacity Not Published 1.3 gal (MFWD differential housing); 0.2 gal (each wheel hub) ▶ PTO & HitchPTO Type Not Published Independent, electro-hydraulic engagement, wet PTO clutch, reversible 540/1000 shaft PTO Rear Not Published 540/540E/1000 rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Not Published Category II (telescoping draft links with Category II balls) Hitch Lift Capacity Not Published 7,158 lb; 8,157 lb throughout lift range at hitch ball; 11,122 lb / 12,515 lb maximum Hitch Lift Capacity (at 24”) Not Published 6,975 lb; 7,868 lb throughout lift range Lift Control Type Not Published Electro-hydraulic hitch with fender controls, lower-link draft sensing ▶ Transmission & DrivetrainTransmission Type 12x12 electronic power shuttle CommandQuad 16F/16R manual with electronic range and gear shifting, AutoClutch and wet traction clutch (standard); CommandQuad 16F/16R Auto, CommandQuad 16F/16R manual with creeper, or Command8 32F/16R (optional) No. of Speeds 12 forward / 12 reverse 16F/16R (CommandQuad, standard); 32F/16R (Command8, optional) Max Travel Speed (Forward) Not Published 22.0 mph (D4, 16/16 transmission, 480/70R28 rear tires) Max Travel Speed (Reverse) Not Published 18.6 mph Clutch Not Published Wet traction clutch with AutoClutch Differential Lock & Limited Slip Options Not Published Electro-hydraulic differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Cab standard with air conditioning; mechanical front-wheel drive (MFWD) Steering Not Published Hydrostatic power steering Brakes Not Published Hydraulic wet disc, self-equalizing and self-adjusting, lockable turning brakes; electronic park brake Seat Suspension & Adjustability Air ride seat (standard); instructor seat available Not Published Front Axle Type Class 1.0 HD heavy-duty front axle MFWD, electro-hydraulic engagement, planetary final drives Front Axle Rating Not Published 7,937 lb (MFWD closed center); 7,055 lb (MFWD open center) Drawbar Capacity Not Published 2,756 lb (standard drawbar, 9.8 in extended); 2,205 lb (standard, 13.8 in extended); 3,197 lb (heavy duty, 9.8 in extended); 2,646 lb (heavy duty, 13.8 in extended) ▶ Dimensions & ManeuverabilityOverall Width Not Published 87 in (with fender extension); 74 in (without fender extension); 66.9 in (narrow cab, without fender extension) Wheelbase Not Published 88.6 in Ground Clearance Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 106.1 in Overall Length Not Published 147.8 in ▶ WeightTractor Weight (Base) Not Published 9,811 lb (base machine weight, with all fluids) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Not Published 320/85R24 (12.4R24) R1-W radial front and 460/85R30 (18.4R30) R1-W radial rear standard; optional 11.2R28/13.6R38, 380/70R20/480/70R28, 13.6R24/16.9R34, 380/70R24/480/70R34 R1; R3 44x18-20/23.1-26; R4 12.5/80-18/19.5L-24 R1 Agricultural - Front Not Published 320/85R24 (12.4R24) R1-W radial R1 Agricultural - Rear Not Published 460/85R30 (18.4R30) R1-W radial R3 Turf - Front Not Published 44x18-20 R3 Turf - Rear Not Published 23.1-26 R4 Industrial - Front Not Published 12.5/80-18 R4 Industrial - Rear Not Published 19.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Global carrier in base; John Deere 500-style carrier optional (540R) Loader Model 630LU; 635LU 540R (non self-leveling and mechanical self-leveling) Loader Lift Height 143.9 in (630LU and 635LU) 540R: 141.5 in Loader Lift Capacity (Full Height) 630LU: 2,764 lb; 635LU: 3,882 lb (at max height, at 31.5 in) 540R NSL: 4,246 lb (measured at pivot) Loader Breakout Force Not Published 540R NSL: 4,945 lbf (measured at pivot) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
