▶ EngineAlternator 70 A, 12 V 70 A, 12 V Engine Type Yanmar Diesel Engine 4-cycle diesel, water-cooled (natural aspiration) Displacement 100.2 in³ 100.2 in³ Engine Model 3TNV88C-DKTF 3TNV88C-DKTF No. of Cylinders 3 3 Rated Engine Speed 3000 3000 rpm Engine Manufacturer Yanmar Yanmar Engine Power (Gross) 37 hp 37 hp Engine Emissions Constraints Tier 4 Tier 4 PTO Power — 30.2 hp Air Cleaner — Dual dry Fuel System — CRDI Cooling System Type — Water-cooled ▶ WeightWeight with ROPS and Loader 3,417 lbs Not Applicable Weight with Cab and Loader — 4,469 lb ▶ HydraulicsPump Type Dual Gear Pump Dual Gear Pump Steering Flow 4.6 gpm 4.6 gpm Implement Flow 6.3 gpm 6.3 gpm Total Hydraulic Flow 10.9 gpm 10.9 gpm Overall Hydraulic Pump Flow 6.4 gpm 24.2 lpm 10.9 gpm No. of Optional Remote Valves 1 1 No. of Standard Remote Valves 1 1 Hydraulic System Type — Separate reservoir, independent fully live Rear Remote Hydraulic Flow — Not Published ▶ PTO & HitchPTO Type Independent Independent Lift Control Type Position Position Hitch Lift Capacity 2,646 lbs 2,646 lb Mid-PTO Availability NOT_FOUND - no source reviewed explicitly lists a mid-PTO specification for the RK37SC 2000 (option) PTO Rear — 540 rpm Category, 3-Point Hitch — Category I Hitch Lift Capacity (at 24”) — 1,764 lb ▶ Tire OptionsR3 Turf - Rear 41x14-20 41x14-20 R3 Turf - Front 27x10.5-15 27X10.5-15 R4 Industrial - Rear 12.5x20 12.5X20 R4 Industrial - Front 27x10.5-15 27X10.5-15 Tire Size & Options — R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Rear — 12.4-24 R1 Agricultural - Front — 8.0-16 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 9.0 gal Coolant Capacity — 7.4 qt Crankcase Capacity — 6.0 qt Front Axle Fluid Capacity — 8.7 qt Transmission / Hydraulic System Capacity — 9.25 gal ▶ Loader & AttachmentsLoader Model front-end loader L102 Loader Lift Height — 102 in Loader Breakout Force — 3,435 lb Quick Attach Loader System — L102: Skid-steer compatible quick-attach Loader Lift Capacity (Full Height) — 2,116 lb ▶ Transmission & DrivetrainClutch electro-hydraulic single plate dry clutch (8.86" diameter) Transmission Type 12F/12R Syncro Shuttle Transmission Partial synchromesh shuttle shift (high/low selector) Max Travel Speed (Forward) 21.8 mph [km/h] 21.8 mph Differential Lock & Limited Slip Options Differential Lock 4WD, Differential Lock No. of Speeds — 12F/12R Max Travel Speed (Reverse) — Not Published ▶ Chassis, Steering & ControlsBrakes Wet Disc Wet Disc Steering — Hydrostatic Frame Type — Not Published Front Axle Type — 4WD front axle, center-pivot, reverse Eliot type Drawbar Capacity — Not Published Front Axle Rating — Not Published Seat Suspension & Adjustability — Not Published ▶ Dimensions & ManeuverabilityWheelbase — 66.1 in Overall Width — 58.0 in Ground Clearance — 12.8 in Height to Top of ROPS — Not Applicable Height to Top of Cab Model — Not Published Height to Top of ROPS (folded) — Not Applicable Min. Turn Radius without Brakes — 116 in Overall Length with 3-Point Hitch — 128 in ▶ WarrantyWarranty Length & Coverage — Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) ▶ ITC Company AccessoriesAccessories that fit
