▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 4TNV86T-CR 3TNV80F-SDKTFF Engine Type 4-cycle, inline, water-cooled, turbocharged diesel Water cooled, 4-cycle diesel No. of Cylinders 4 3 Displacement 127.6 in³ 77.3 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 55.1 hp 24 hp PTO Power 44.9 hp 18.8 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled, forced circulation with fan Water cooled, forced circulation Air Cleaner Dry dual element Single element Fuel System Common Rail Direct Injection Indirect fuel injection Alternator 70 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Not Published Gear Pump Implement Flow 9.5 gpm 4.18 gpm Steering Flow 5.0 gpm 2.77 gpm Total Hydraulic Flow 14.5 gpm 6.95 gpm Overall Hydraulic Pump Flow 9.5 gpm 6.95 gpm Hydraulic System Type Independent fully live hydraulic pump with separate reservoir; position control with isolating and response control Live, independent Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published Not Published ▶ Fluid CapacityFuel Tank Capacity 15.85 gal 5.81 gal Coolant Capacity 2.5 gal 0.96 gal Crankcase Capacity 5.6 qt 0.71 gal Transmission / Hydraulic System Capacity 9.24 gal 3.83 gal Front Axle Fluid Capacity 2.64 gal 0.85 gal ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered Standard, 2,000 rpm @ 2,875 rpm Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,314 lb 1,323 lb Hitch Lift Capacity (at 24”) 2,945 lb 1,058 lb Lift Control Type Position and draft control Position ▶ Transmission & DrivetrainTransmission Type 16F/16R Syncro Shuttle w/creeper Hydraulic + mechanical H/L with constant-mesh No. of Speeds 16 forward, 16 reverse 2 ranges (high/low), infinite forward and reverse Max Travel Speed (Forward) 18.4 mph 11.2 mph Max Travel Speed (Reverse) 16.1 mph Not Published Clutch Main: dry single disc, mechanical (10.24 in diameter); PTO: multiple wet disc Electro-hydraulic PTO clutch assembly (hydrostatic drive, no traction clutch) Differential Lock & Limited Slip Options 4WD (MFWD) standard; bevel-gear rear differential lock 4WD with differential lock (bevel gears with diff-lock) ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Rigid unit: transmission case, engine and front axle support bolted together Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical, foot operated Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Suspension seat with armrests & retractable seat belt Front Axle Type Center-pivot, reverse Elliot type (4WD) 4WD, center-pivot reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 100.5 in Overall Width 63.8 in 45.8 in Wheelbase 76.2 in 57.5 in Ground Clearance 13.8 in 9.4 in Min. Turn Radius without Brakes Not Published Not Published Height to Top of ROPS 102.1 in 91.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,814 lb 1,610 lb Weight with ROPS and Loader Not Published 2,091 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) R1 Agricultural - Front 9.5x16 6-12 R1 Agricultural - Rear 14.9x24 9.5-16 R3 Turf - Front 12x16.5 20x8-10 R3 Turf - Rear 16.9x24 29x12.5-15 R4 Industrial - Front 12x16.5 20x8-10 R4 Industrial - Rear 16.9x24 27x12.5-15 ▶ Loader & AttachmentsQuick Attach Loader System L110: Skid-steer compatible quick-attach L75: skid-steer compatible quick-attach Loader Model L110 L75 Loader Lift Height L110: 110 in L75: 75.3 in (maximum lift height to pivot pin) Loader Lift Capacity (Full Height) L110: 2,478 lb at pivot pin to full height L75: 947 lb (at pivot pin, to full height) Loader Breakout Force L110: 4,938 lb at pivot pin L75: 1,680 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage 2-year full machine warranty; 8-year, 3,000-hour powertrain warranty (no deductible, parts and labor) Full machine: 2 years or 2,000 hours; Powertrain: 8 years or 3,000 hours (no deductible, parts and labor) ▶ ITC Company AccessoriesAccessories that fit
