▶ EnginePTO Power 18.8 hp — Alternator 40 A, 12 V — Air Cleaner Single element — Engine Type Water cooled, 4-cycle Diesel — Fuel System Indirect Fuel Injection — Displacement 77.3 in³ — Engine Model 3TNV80F-SDKTFF — No. of Cylinders 3 — Rated Engine Speed 3000 rpm — Cooling System Type Water cooled, forced circulation — Engine Manufacturer Yanmar — Engine Power (Gross) 23.9 hp — Engine Emissions Constraints Tier 4 — ▶ WeightWeight with ROPS and Loader 2,091 lb — Weight with Cab and Loader Not Published — ▶ WarrantyWarranty Length & Coverage Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first) — ▶ HydraulicsPump Type Gear Pump — Steering Flow Not Published — Implement Flow Not Published — Total Hydraulic Flow 6.95 gpm — Hydraulic System Type Hydrostatic — Rear Remote Hydraulic Flow Not Published — Overall Hydraulic Pump Flow 26.3 lpm (6.95 US gpm) — No. of Optional Remote Valves NOT FOUND — no source explicitly states the number of optional remote valves available for the RK24. Sources confirm 1 standard rear remote set is included, but do not specify optional add-on valve counts. — No. of Standard Remote Valves 1 — ▶ PTO & HitchPTO Rear 540 rpm — PTO Type Independent PTO — Lift Control Type Position control — Hitch Lift Capacity 1,323 lb — Mid-PTO Availability Standard, 2,000 rpm @ 2,875 rpm — Category, 3-Point Hitch Category I — Hitch Lift Capacity (at 24”) Not Published — ▶ Tire OptionsR3 Turf - Rear 29X12.5-15 — R3 Turf - Front 20X8-10 — Tire Size & Options R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt) — R4 Industrial - Rear 27X12.5-15 — R4 Industrial - Front 20X8-10 — R1 Agricultural - Rear 9.5-16 — R1 Agricultural - Front 6-12 — ▶ Fluid CapacityCoolant Capacity 3.6 ℓ (0.96US gal) — Crankcase Capacity 2.7 ℓ ( 0.71 US gal) — Fuel Tank Capacity 5.81 gal — Front Axle Fluid Capacity 3.2ℓ (0.85 US gal) — Transmission / Hydraulic System Capacity 14.5ℓ (3.83 US gal) — ▶ Loader & AttachmentsLoader Lift Height 75.3 — Loader Breakout Force 1,680 lb — Quick Attach Loader System Skid-Steer Compatible Quick-Attach — Loader Lift Capacity (Full Height) 947 lb — ▶ Transmission & DrivetrainClutch Not Published — No. of Speeds 2 Range (High/Low) — Transmission Type Hydraulic + Mechanical H/L with constant-mesh — Max Travel Speed (Forward) 10.5 mph — Max Travel Speed (Reverse) Not Published — Differential Lock & Limited Slip Options Differential lock (bevel gears with diff-lock) — ▶ Chassis, Steering & ControlsBrakes Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation — Steering Hydrostatic Power steering system — Frame Type Not Published — Front Axle Type Center-pivot, reverse Eliot type — Drawbar Capacity Not Published — Front Axle Rating Not Published — Seat Suspension & Adjustability Not Published — ▶ Dimensions & ManeuverabilityWheelbase 57.5 in — Overall Width 45.8 in — Ground Clearance 9.4 in — Height to Top of ROPS 91.3 in — Height to Top of Cab Model Not Published — Height to Top of ROPS (folded) Not Published — Min. Turn Radius without Brakes Not Published — Overall Length with 3-Point Hitch 100.5 in — ▶ ITC Company AccessoriesAccessories that fit None tagged yet
