Bad Boy Tractors 4025 vs Rural King RK24

Across 7 measurable specs, the Bad Boy Tractors 4025 leads 7 categories to 0. Machine pages: Bad Boy Tractors 4025 and Rural King RK24.

Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.

Category Verdict

Full Spec Sheet

Every published spec, side by side, including the details the graphs above don't chart.

Spec	Bad Boy Tractors4025	Rural KingRK24

▶Engine
PTO Power	540 rpm, 1st stage	18.8 hp
Alternator	50 A, 12 V	40 A, 12 V
Air Cleaner	Present (standard equipment)	Single element
Engine Type	Vertical, water cooled 4-cycle, diesel engine	Water cooled, 4-cycle Diesel
Fuel System	Diesel fuel system with fuel injection pump	Indirect Fuel Injection
Displacement	104.6 in³	77.3 in³
No. of Cylinders	3	3
Rated Engine Speed	2100 rpm	3000 rpm
Cooling System Type	Pressurized Radiator	Water cooled, forced circulation
Engine Manufacturer	A1700N6, A1700N5, A1700N4	Yanmar
Engine Power (Gross)	24.5 hp	23.9 hp
Engine Emissions Constraints	Not Published	Tier 4
Engine Model	—	3TNV80F-SDKTFF
▶Weight
Tractor Weight (Base)	3,496.5 lb (3,497 lbs), 3,728 lb (3,728 lbs)	—
Weight with ROPS and Loader	Not Published	2,091 lb
Weight with Cab and Loader	Not Published	Not Published
▶Warranty
Warranty Length & Coverage	6-year powertrain warranty	Full-machine: 24 months/2,000 hours; Powertrain: 96 months/3,000 hours (whichever comes first)
▶Hydraulics
Pump Type	Gear type (primary 0.8 in³/rev, secondary 0.4 in³/rev)	Gear Pump
Steering Flow	4.0 gpm	Not Published
Implement Flow	7.5 gpm	Not Published
Total Hydraulic Flow	11.5 gpm (4.0 + 7.5)	6.95 gpm
Hydraulic System Type	Not Published	Hydrostatic
System Operating Pressure	463 lbf/cm² maximum	—
Rear Remote Hydraulic Flow	Not Published	Not Published
Overall Hydraulic Pump Flow	11.5 gpm	26.3 lpm (6.95 US gpm)
No. of Optional Remote Valves	Optional (Up to 2)	NOT FOUND — no source explicitly states the number of optional remote valves available for the RK24. Sources confirm 1 standard rear remote set is included, but do not specify optional add-on valve counts.
No. of Standard Remote Valves	Not Published	1
▶PTO & Hitch
PTO Rear	540 rpm	540 rpm
PTO Type	Independent	Independent PTO
Lift Control Type	Position control type	Position control
Hitch Lift Capacity	2,425 lb @ 24 in behind lift point	1,323 lb
Mid-PTO Availability	Not Published	Standard, 2,000 rpm @ 2,875 rpm
Category, 3-Point Hitch	Category 1	Category I
Hitch Lift Capacity (at 24”)	2,425 lb @ 24 in behind lift point	Not Published
▶Tire Options
R3 Turf - Rear	Not Published	29X12.5-15
R3 Turf - Front	Not Published	20X8-10
Tire Size & Options	OEM website lists IND tires 25X8.50-14 / 15-19.5; Operator Manual spec based on 8.0-16 / 12.4-24	R4 Industrial (Std), R3 Turf (Opt) R1 Ag (Opt), Goodyear R14 (Opt)
R4 Industrial - Rear	15-19.5	27X12.5-15
R4 Industrial - Front	25X8.50-14	20X8-10
R1 Agricultural - Rear	12.4-24 6PR	9.5-16
R1 Agricultural - Front	8.0-16 4PR	6-12
▶Fluid Capacity
Coolant Capacity	5.0 ℓ (1.32 u.s. gal)	3.6 ℓ (0.96US gal)
Crankcase Capacity	4.3 ℓ (1.14 u.s. gal)	2.7 ℓ ( 0.71 US gal)
Fuel Tank Capacity	27 ℓ (7.13 u.s. gal)	5.81 gal
Front Axle Fluid Capacity	Not Published	3.2ℓ (0.85 US gal)
Transmission / Hydraulic System Capacity	HST: 9.77 gal	14.5ℓ (3.83 US gal)
▶Loader & Attachments
Loader Lift Height	104 in	75.3
Loader Breakout Force	3,660 lb	1,680 lb
Quick Attach Loader System	SSQA	Skid-Steer Compatible Quick-Attach
Loader Lift Capacity (Full Height)	2,200 lb (pivot pin)	947 lb
▶Transmission & Drivetrain
Clutch	None (HST)	Not Published
No. of Speeds	3 Range	2 Range (High/Low)
Transmission Type	HST (Hydrostatic Transmission) with shuttle type	Hydraulic + Mechanical H/L with constant-mesh
Max Travel Speed (Forward)	Not Published	10.5 mph
Max Travel Speed (Reverse)	Not Published	Not Published
Differential Lock & Limited Slip Options	Differential lock	Differential lock (bevel gears with diff-lock)
▶Chassis, Steering & Controls
Brakes	Wet, Multi-Disc	Wet Disc, Foot operated, independent with provision of inter lock for simultaneous operation
Steering	Hydrostatic power steering	Hydrostatic Power steering system
Frame Type	Not Published	Not Published
Front Axle Type	Not Published	Center-pivot, reverse Eliot type
Drawbar Capacity	Not Published	Not Published
Front Axle Rating	Not Published	Not Published
Seat Suspension & Adjustability	Not Published	Not Published
▶Dimensions & Maneuverability
Wheelbase	65.8 in (65.79 in.)	57.5 in
Overall Width	57.1 in (57.13 in.) [ROPS Model], 55.6 in (55.63 in.) [Cabin Model]	45.8 in
Overall Length	134.9 in (134.88 in.)	—
Ground Clearance	13.2 in (13.19 in.) [ROPS Model], 13.5 in (13.50 in.) [Cabin Model]	9.4 in
Height to Top of ROPS	104.1 in (104.06 in.) [ROPS Model], 88.9 in (88.9 in.) [Cabin Model]	91.3 in
Height to Top of Cab Model	Not Published	Not Published
Height to Top of ROPS (folded)	Not Published	Not Published
Min. Turn Radius without Brakes	Not Published	Not Published
Overall Length with 3-Point Hitch	134.88 in	100.5 in
▶ITC Company Accessories
Accessories that fit	Brush Guard Side Guards $199.99 Bolt onto the side of the OEM guard and offers wrap around protection Branson TYM 15/20 Series--Bad Boy 40/50 Series Brush Screen $250.00	None tagged yet

Bad Boy Tractors 4025 vs Rural King RK24: Quick Answers

Which has more horsepower, the Bad Boy Tractors 4025 or the Rural King RK24?

The Bad Boy Tractors 4025 leads on engine hp at 24.5 hp hp, compared to 23.9 hp hp for the Rural King RK24.

Which is heavier, the Bad Boy Tractors 4025 or the Rural King RK24?

The Bad Boy Tractors 4025 leads on weight at 3,496.5 lb lb, compared to 2,091 lb lb for the Rural King RK24.

Which has more loader lift capacity, the Bad Boy Tractors 4025 or the Rural King RK24?

The Bad Boy Tractors 4025 leads on loader lift at 2,200 lb lb, compared to 947 lb lb for the Rural King RK24.

Which has more three-point hitch lift capacity, the Bad Boy Tractors 4025 or the Rural King RK24?

The Bad Boy Tractors 4025 leads on 3-pt lift (24 in) at 2,425 lb lb, compared to 1,323 lb lb for the Rural King RK24.
