▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 4TNV86T-CR 3TNV88-CR Engine Type 4-cycle, inline, water-cooled, turbocharged diesel Natural aspiration No. of Cylinders 4 3 Displacement 127.6 in³ 100.2 in³ Rated Engine Speed 2800 rpm 3000 rpm Engine Power (Gross) 55.1 hp 37.4 hp PTO Power 44.9 hp 30.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled, forced circulation with fan Liquid-cooled Air Cleaner Dry dual element Dual dry Fuel System Common Rail Direct Injection Common Rail Direct Injection Alternator 70 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Dual gear pump Implement Flow 9.5 gpm 6.4 gpm Steering Flow 5.0 gpm 4.6 gpm Total Hydraulic Flow 14.5 gpm 11.0 gpm Overall Hydraulic Pump Flow 9.5 gpm 6.4 gpm Hydraulic System Type Independent fully live hydraulic pump with separate reservoir; position control with isolating and response control Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 1 No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 15.85 gal 9.0 gal Coolant Capacity 2.5 gal 7.4 qt Crankcase Capacity 5.6 qt 6.0 qt Transmission / Hydraulic System Capacity 9.24 gal 9.25 gal Front Axle Fluid Capacity 2.64 gal 8.7 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability No mid-PTO offered No mid-PTO offered Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 3,314 lb 2,646 lb Hitch Lift Capacity (at 24”) 2,945 lb 1,764 lb Lift Control Type Position and draft control Position ▶ Transmission & DrivetrainTransmission Type 16F/16R Syncro Shuttle w/creeper 12F/12R Syncro Shuttle No. of Speeds 16 forward, 16 reverse 12 forward, 12 reverse Max Travel Speed (Forward) 18.4 mph 15.0 mph Max Travel Speed (Reverse) 16.1 mph Not Published Clutch Main: dry single disc, mechanical (10.24 in diameter); PTO: multiple wet disc Single plate dry clutch (8.86 in diameter); hydraulic clutch assembly for Independent PTO models Differential Lock & Limited Slip Options 4WD (MFWD) standard; bevel-gear rear differential lock 4WD, differential lock ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Transmission case, clutch housing, engine and front axle support bolted together to form a rigid unit Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc, mechanical, foot operated Wet disc Seat Suspension & Adjustability Suspension seat with armrests and retractable seat belt, standard Suspension seat with armrests and retractable seat belt, standard Front Axle Type Center-pivot, reverse Elliot type (4WD) Center-pivot, reverse Elliot type (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 141.3 in 126 in Overall Width 63.8 in 53.5 in Wheelbase 76.2 in 64.5 in Ground Clearance 13.8 in 12.8 in Min. Turn Radius without Brakes Not Published 116 in Height to Top of ROPS 102.1 in 94.5 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,814 lb 3,065 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) Titan (USA): R4 Industrial (Std), R1 Agricultural (Opt), R3 Turf (Opt) R1 Agricultural - Front 9.5x16 7-16 R1 Agricultural - Rear 14.9x24 11.2x24 R3 Turf - Front 12x16.5 28x8.5-15 R3 Turf - Rear 16.9x24 41x14-20 R4 Industrial - Front 12x16.5 10-16.5 R4 Industrial - Rear 16.9x24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System L110: Skid-steer compatible quick-attach L102: Skid-steer compatible quick-attach Loader Model L110 L102 Loader Lift Height L110: 110 in L102: 102 in Loader Lift Capacity (Full Height) L110: 2,478 lb at pivot pin to full height L102: 2,116 lb at pivot pin to full height Loader Breakout Force L110: 4,938 lb at pivot pin L102: 3,435 lb at pivot pin ▶ WarrantyWarranty Length & Coverage 2-year full machine warranty; 8-year, 3,000-hour powertrain warranty (no deductible, parts and labor) 2-year full machine warranty; 8-year, 3,000-hour powertrain warranty (no deductible, parts and labor) ▶ ITC Company AccessoriesAccessories that fit
