▶ EngineEngine Manufacturer Deutz FPT Industrial Engine Model TCD2.9 L4 F5C Engine Type Turbocharged 4-cylinder diesel, turbocharged No. of Cylinders 4 4 Displacement 177.0 in³ 207 in³ Rated Engine Speed 2200 rpm 2300 rpm Engine Power (Gross) 74 hp 74 hp PTO Power 64.1 hp 65 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Common Rail Direct Injection Common rail fuel injection Alternator 95 A, 12 V 120 A ▶ HydraulicsPump Type Not Published Open center, dual pumps: implement pump plus dedicated steering and services pump Implement Flow 10.3 gpm 12.5 gpm Steering Flow 5.8 gpm 7.3 gpm (mechanical shuttle); 9.5 gpm (power shuttle) Total Hydraulic Flow 16.1 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Overall Hydraulic Pump Flow 10.3 gpm 19.8 gpm (mechanical shuttle; 12.5 + 7.3, computed); 22.0 gpm (power shuttle; 12.5 + 9.5, computed) Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 2 Not Published No. of Optional Remote Valves 3 Up to 3 rear remotes ▶ Fluid CapacityFuel Tank Capacity 23.8 gal 23.8 gal Coolant Capacity 10.6 qt Not Published Crankcase Capacity 8.5 qt Not Published Transmission / Hydraulic System Capacity 18.0 gal Not Published Front Axle Fluid Capacity 17.4 qt Not Published ▶ PTO & HitchPTO Type Independent Fully independent PTO Rear 540/750 rpm 540 rpm at 1,958 engine rpm (standard); 540E at 1,592 engine rpm (optional) Mid-PTO Availability No mid-PTO offered Not Published Category, 3-Point Hitch Category II Category II / I Hitch Lift Capacity 5,115 lb Not Published Hitch Lift Capacity (at 24”) 3,414 lb 3,664 lb Lift Control Type Position / Draft / Mechanical Mechanical draft control; top link draft sensing ▶ Transmission & DrivetrainTransmission Type 16F/16R Power Shuttle w/creeper 8x8 mechanical synchro shuttle (standard); 8x8 hydraulic power shuttle, 12x12 mechanical synchro shuttle or 12x12 hydraulic power shuttle (optional); creeper available with the power shuttle transmissions No. of Speeds 16 forward, 16 reverse (creeper interlock) 8F/8R (standard); 12F/12R (optional); 12F/12R or 20F/20R with creeper (optional) Max Travel Speed (Forward) 18.9 mph 20.1 mph (8x8 and 12x12, 20 mph transmissions); 24.1 mph (optional 24 mph 12x12 transmission, 4WD only) Max Travel Speed (Reverse) Not Published 20.1 mph Clutch Single plate dry clutch (11.81 in diameter); hydraulic clutch assembly for Independent PTO models Mechanical dry disc (mechanical shuttle); wet disc (power shuttle) Differential Lock & Limited Slip Options 4WD, differential lock Mechanical rear differential lock ▶ Chassis, Steering & ControlsFrame Type Unit frame: engine, clutch housing, transmission and front axle support bolted into one rigid assembly Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Hydraulic wet disc Seat Suspension & Adjustability High-back suspension seat with extension Air-suspension seat with integrated armrest and 10° swivel (optional, cab); full-size instructor seat with seat belt (cab) Front Axle Type Center-pivot, reverse Elliot type (4WD) Heavy-duty 2WD front axle; electronic 4WD front axle (optional on T4.75, standard on T4.65) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 157.5 in 151 in Overall Width 76.4 in Not Published Wheelbase 86.1 in 85.8 in (2WD); 83.9 in (4WD) Ground Clearance 18.3 in Not Published Min. Turn Radius without Brakes 162.8 in 134 in (2WD front axle) Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published 76 to 78.9 in Height to Top of Cab Model 103.3 in 94.8 to 97.8 in ▶ WeightTractor Weight (Base) 6,052 lb 5,027 lb (2WD ROPS); 5,952 lb (4WD ROPS) Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Titan (USA): R4 Industrial (Std), R3 Turf (Opt), R1 Agricultural (Opt) Not Published R1 Agricultural - Front 11.2-24 Not Published R1 Agricultural - Rear 16.9-30 Not Published R3 Turf - Front 12.0-20.5 Not Published R3 Turf - Rear 22.4-25.5 Not Published R4 Industrial - Front 15-19.5 Not Published R4 Industrial - Rear 18.4-24 Not Published ▶ Loader & AttachmentsQuick Attach Loader System L135SL: Skid-steer compatible quick coupler, self-leveling Skid-steer-style or Euro-style quick attach faceplate Loader Model L135SL Factory-fit: 655TL (NSL or MSL); field-fit: 622TL (NSL), 627TL (MSL) Loader Lift Height L135SL: 135.5 in 655TL NSL: 126 in; 655TL MSL: 125 in; 622TL: 121 in; 627TL: 121 in Loader Lift Capacity (Full Height) L135SL: 3,223 lb at pivot pin to full height 655TL NSL: 2,478 lb; 655TL MSL: 3,179 lb; 622TL: 1,830 lb; 627TL: 2,557 lb (at max height, 31.5 in forward of the bucket pivot point) Loader Breakout Force L135SL: 5,335 lb at pivot pin 655TL NSL: 3,739 lb; 622TL: 3,042 lb; 627TL: 3,307 lb (at 31.5 in forward of the bucket pivot point) ▶ WarrantyWarranty Length & Coverage Not Published Not Published
