▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV74F 3TNV74F Engine Type Diesel, swirl chamber combustion, naturally aspirated Naturally aspirated, indirect injection, liquid-cooled diesel No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 19 hp 19.4 hp PTO Power 13.4 hp 14.2 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Water-cooled Air Cleaner Dry, single filter element Not Published Fuel System Indirect injection (swirl chamber) Indirect Injection Alternator 40 A, 12 V 45 A, 12 V ▶ HydraulicsPump Type Single gear pump with flow divider Not Published Implement Flow 4.17 gpm 4.1 gpm Steering Flow 2.11 gpm 2.11 gpm Total Hydraulic Flow 6.28 gpm (4.17 + 2.11, computed) 6.2 gpm Overall Hydraulic Pump Flow Not Published 6.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.7 qt Not Published Crankcase Capacity 2.1 qt Not Published Transmission / Hydraulic System Capacity 3.6 gal Not Published Front Axle Fluid Capacity 2.6 qt Not Published ▶ PTO & HitchPTO Type Transmission-driven (over-running clutch) Independent PTO Rear Not Published 540 @ 2942 rpm Mid-PTO Availability Not Published Available; 2500 @ 2958 rpm Category, 3-Point Hitch Category I CAT I Narrow with Check Chains Hitch Lift Capacity 1,100 lb 680 lb Hitch Lift Capacity (at 24”) 679 lb Not Published Lift Control Type Position control Position ▶ Transmission & DrivetrainTransmission Type Hydrostatic (HST) HST - 2 range No. of Speeds Infinite (2-range HST) Infinite Max Travel Speed (Forward) 7.8 mph Not Published Max Travel Speed (Reverse) 7.8 mph Not Published Clutch Dry, single Dry-Single Differential Lock & Limited Slip Options Not Published Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Power steering Brakes Wet disc Wet Disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.5 in Wheelbase 53.1 in 53.1 in Ground Clearance 8.3 in 8.3 in Min. Turn Radius without Brakes Not Published 7.2 ft Height to Top of ROPS 86.6 in Not Published Height to Top of ROPS (folded) 60 in Not Published Height to Top of Cab Model Not Published 79.6 in Overall Length 94.2 in 94.2 in ▶ WeightTractor Weight (Base) 1,433 lb 1,800 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published 2,219 lb (1,800 + 419, computed; 6.1 gal loader shipping weight) ▶ Tire OptionsTire Size & Options Turf: 18x8.5-10 front, 26x12-12 rear; Industrial: 18x8.5-10 front, 26x12-12 rear Agricultural, Industrial, Turf R1 Agricultural - Front 16x7.50-9 18x8.5-10 R1 Agricultural - Rear 24x12.00-12 26x12-12 R3 Turf - Front Not Published 18x8.5-10 R3 Turf - Rear Not Published 26x12-12 R4 Industrial - Front 18x8.5-10 18x8.5-10 R4 Industrial - Rear 26x12-12 26x12-12 ▶ Loader & AttachmentsQuick Attach Loader System BL90: Standard pin-on (skid steer quick-attach optional) 23L: Skid steer style quick coupler, standard Loader Model BL90 23L Loader Lift Height BL90: 71.3 in 71.3 in Loader Lift Capacity (Full Height) BL90: 617 lb (at pivot pin, full height) 617 lb (at pivot pin) Loader Breakout Force BL90: 1,235 lbf (at pivot pin, ground level) 1,235 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic two years or 1,000 hours; powertrain 7 years or 2,000 hours Two Year All Aggregate (bumper to bumper) Warranty and Five-Year Limited Powertrain Warranty
