▶ EngineEngine Manufacturer Kukje LS Engine Model 3T90L-ATC L3C19-D2 Engine Type Diesel, liquid-cooled 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 3 3 Displacement 109.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Not Published 29.7 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Dry element Dry Fuel System Not Published CRDI (Delphi common rail direct injection) Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow Not Published 8.2 gpm Steering Flow Not Published 4.1 gpm Total Hydraulic Flow Not Published 12.3 gpm Overall Hydraulic Pump Flow Not Published 12.3 gpm Hydraulic System Type Not Published Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 0 No. of Optional Remote Valves Not Published 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 7.4 gal Coolant Capacity Not Published 1.9 gal Crankcase Capacity Not Published 1.5 gal Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Transmission-driven Independent (wet disc clutch) PTO Rear 540 / 1000 rpm Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Synchro Shuttle No. of Speeds 12F/12R F12 x R12 Max Travel Speed (Forward) Not Published 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Not Published Dry single clutch Differential Lock & Limited Slip Options Not Published Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.7 in 121 in Overall Width 60 in 54 in (R1); 66 in (R4) Wheelbase 68.8 in 69 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes Not Published 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 86.4 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,624 lb 2,866 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 8-18 7-14 R1 Agricultural - Rear 12.4-28 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model Not Published LL3301 Loader Lift Height Not Published LL3301: 94 in Loader Lift Capacity (Full Height) Not Published LL3301: 1,688 lb (at pivot pin, full height) Loader Breakout Force Not Published LL3301: 2,855 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited warranty
