▶ EngineEngine Manufacturer Kukje LS Mtron Engine Model 3T90L-ATC L3CRV-T5 Engine Type Diesel, liquid-cooled 3-cylinder, turbocharged, liquid-cooled diesel No. of Cylinders 3 3 Displacement 109.5 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 35 hp 35 hp PTO Power Not Published Gear: 29.7 hp; HST: 28 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid cooled Air Cleaner Dry element Replaceable primary and inner elements Fuel System Not Published Electronically controlled common rail direct injection Alternator Not Published 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear Implement Flow Not Published 8.2 gpm Steering Flow Not Published Gear: 4.2 gpm; HST: 5.3 gpm Total Hydraulic Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Overall Hydraulic Pump Flow Not Published Gear: 12.4 gpm; HST: 13.5 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published 1 No. of Optional Remote Valves Not Published Up to 2 (second valve optional) ▶ Fluid CapacityFuel Tank Capacity 10.6 gal 10.5 gal Coolant Capacity Not Published 7.5 qt Crankcase Capacity Not Published 5.8 qt Transmission / Hydraulic System Capacity Not Published 8.5 gal Front Axle Fluid Capacity Not Published 6.87 qt ▶ PTO & HitchPTO Type Transmission-driven Independent, electro-hydraulic engagement PTO Rear 540 / 1000 rpm 540 rpm Mid-PTO Availability Not Published Standard (2000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity Not Published 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,345 lb Lift Control Type Not Published Position control (draft control optional) ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal No. of Speeds 12F/12R Gear: 12F/12R; HST: 3-range Max Travel Speed (Forward) Not Published Gear: 14.2 mph; HST: 14.8 mph Max Travel Speed (Reverse) Not Published Gear: 13.63 mph; HST: 13.60 mph Clutch Not Published Gear: dry single disc (9.4 in); HST: n/a Differential Lock & Limited Slip Options Not Published Mechanical rear differential lock (pedal) ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Power steering Brakes Wet disc Wet multi-disc Seat Suspension & Adjustability Not Published Adjustable suspension seat (fore/aft, weight and height adjustment) Front Axle Type 4WD (MFWD) Four-wheel drive (FWD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 129.7 in 119 in Overall Width 60 in 66.4 in Wheelbase 68.8 in 66 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes Not Published 9.2 ft (with brake applied) Height to Top of ROPS 86.4 in 92.7 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,624 lb Gear: 2,804 lb; HST: 2,870 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front 8-18 7-14 R1 Agricultural - Rear 12.4-28 11.2-24 R3 Turf - Front Not Published 25x8.50-14 R3 Turf - Rear Not Published 41x14.00-20 R4 Industrial - Front Not Published 25x8.50-14 R4 Industrial - Rear Not Published 43x16.00-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published New Holland Quick Mount loader; optional skid steer quick attach plates Loader Model Not Published 250TLA Loader Lift Height Not Published 250TLA: 104 in Loader Lift Capacity (Full Height) Not Published 250TLA: 1,822 lb Loader Breakout Force Not Published 250TLA: 3,257 lb ▶ WarrantyWarranty Length & Coverage Not Published Boomer Guard6 limited warranty: 2 years/750 hours full coverage plus 4 more years of powertrain coverage (6 years/1,500 hours total)
