| Engine Manufacturer | LS Mtron | Kukje |
|---|
| Engine Model | L3CRV-T5 | 3T90L-ATC |
|---|
| Engine Type | 3-cylinder, turbocharged, liquid-cooled diesel | Diesel, liquid-cooled |
|---|
| No. of Cylinders | 3 | 3 |
|---|
| Displacement | 114.7 in³ | 109.5 in³ |
|---|
| Rated Engine Speed | 2600 rpm | 2600 rpm |
|---|
| Engine Power (Gross) | 35 hp | 35 hp |
|---|
| PTO Power | Gear: 29.7 hp; HST: 28 hp | Not Published |
|---|
| Engine Emissions Constraints | Tier 4 | Not Published |
|---|
| Cooling System Type | Liquid cooled | Liquid-cooled |
|---|
| Air Cleaner | Replaceable primary and inner elements | Dry element |
|---|
| Fuel System | Electronically controlled common rail direct injection | Not Published |
|---|
| Alternator | 70 A, 12 V | Not Published |
|---|
|
|---|
| Pump Type | Gear | Not Published |
|---|
| Implement Flow | 8.2 gpm | Not Published |
|---|
| Steering Flow | Gear: 4.2 gpm; HST: 5.3 gpm | Not Published |
|---|
| Total Hydraulic Flow | Gear: 12.4 gpm; HST: 13.5 gpm | Not Published |
|---|
| Overall Hydraulic Pump Flow | Gear: 12.4 gpm; HST: 13.5 gpm | Not Published |
|---|
| Hydraulic System Type | Open center | Not Published |
|---|
| Rear Remote Hydraulic Flow | Not Published | Not Published |
|---|
| No. of Standard Remote Valves | 1 | Not Published |
|---|
| No. of Optional Remote Valves | Up to 2 (second valve optional) | Not Published |
|---|
|
|---|
| Fuel Tank Capacity | 10.5 gal | 10.6 gal |
|---|
| Coolant Capacity | 7.5 qt | Not Published |
|---|
| Crankcase Capacity | 5.8 qt | Not Published |
|---|
| Transmission / Hydraulic System Capacity | 8.5 gal | Not Published |
|---|
| Front Axle Fluid Capacity | 6.87 qt | Not Published |
|---|
|
|---|
| PTO Type | Independent, electro-hydraulic engagement | Transmission-driven |
|---|
| PTO Rear | 540 rpm | 540 / 1000 rpm |
|---|
| Mid-PTO Availability | Standard (2000 rpm) | Not Published |
|---|
| Category, 3-Point Hitch | Category I | Category I |
|---|
| Hitch Lift Capacity | 1,808 lb | Not Published |
|---|
| Hitch Lift Capacity (at 24”) | 1,345 lb | Not Published |
|---|
| Lift Control Type | Position control (draft control optional) | Not Published |
|---|
|
|---|
| Transmission Type | Gear: 12x12 synchronized shuttle shift (SSS); HST: 3-range hydrostatic, dual pedal | Synchronized shuttle |
|---|
| No. of Speeds | Gear: 12F/12R; HST: 3-range | 12F/12R |
|---|
| Max Travel Speed (Forward) | Gear: 14.2 mph; HST: 14.8 mph | Not Published |
|---|
| Max Travel Speed (Reverse) | Gear: 13.63 mph; HST: 13.60 mph | Not Published |
|---|
| Clutch | Gear: dry single disc (9.4 in); HST: n/a | Not Published |
|---|
| Differential Lock & Limited Slip Options | Mechanical rear differential lock (pedal) | Not Published |
|---|
|
|---|
| Frame Type | Not Published | Not Published |
|---|
| Steering | Power steering | Power steering |
|---|
| Brakes | Wet multi-disc | Wet disc |
|---|
| Seat Suspension & Adjustability | Adjustable suspension seat (fore/aft, weight and height adjustment) | Not Published |
|---|
| Front Axle Type | Four-wheel drive (FWD) | 4WD (MFWD) |
|---|
| Front Axle Rating | Not Published | Not Published |
|---|
| Drawbar Capacity | Not Published | Not Published |
|---|
|
|---|
| Overall Length with 3-Point Hitch | 119 in | 129.7 in |
|---|
| Overall Width | 66.4 in | 60 in |
|---|
| Wheelbase | 66 in | 68.8 in |
|---|
| Ground Clearance | Not Published | 12.2 in |
|---|
| Min. Turn Radius without Brakes | 9.2 ft (with brake applied) | Not Published |
|---|
| Height to Top of ROPS | 92.7 in | 86.4 in |
|---|
| Height to Top of ROPS (folded) | Not Published | Not Published |
|---|
| Height to Top of Cab Model | Not Published | Not Published |
|---|
|
|---|
| Tractor Weight (Base) | Gear: 2,804 lb; HST: 2,870 lb | 3,624 lb |
|---|
| Weight with ROPS and Loader | Not Published | Not Published |
|---|
| Weight with Cab and Loader | Not Published | Not Published |
|---|
|
|---|
| Tire Size & Options | R1 Agricultural, R3 Turf, R4 Industrial | Agricultural: 8-18 front / 12.4-28 rear |
|---|
| R1 Agricultural - Front | 7-14 | 8-18 |
|---|
| R1 Agricultural - Rear | 11.2-24 | 12.4-28 |
|---|
| R3 Turf - Front | 25x8.50-14 | Not Published |
|---|
| R3 Turf - Rear | 41x14.00-20 | Not Published |
|---|
| R4 Industrial - Front | 25x8.50-14 | Not Published |
|---|
| R4 Industrial - Rear | 43x16.00-20 | Not Published |
|---|
|
|---|
| Quick Attach Loader System | New Holland Quick Mount loader; optional skid steer quick attach plates | Not Published |
|---|
| Loader Model | 250TLA | Not Published |
|---|
| Loader Lift Height | 250TLA: 104 in | Not Published |
|---|
| Loader Lift Capacity (Full Height) | 250TLA: 1,822 lb | Not Published |
|---|
| Loader Breakout Force | 250TLA: 3,257 lb | Not Published |
|---|
|
|---|
| Warranty Length & Coverage | Boomer Guard6 limited warranty: 2 years/750 hours full coverage plus 4 more years of powertrain coverage (6 years/1,500 hours total) | Not Published |
|---|
