TYM 4215C vs Mahindra 4540 | Side-by-side comparison | ITC Resource Center
Compare Tractors
See horsepower, lift capacity, hydraulic flow, and the numbers that matter to your work. Up to 4 machines, side by side, in graphs built to show which tractor is better at what.
Open center, full-live hydraulic with position and draft controls
Rear Remote Hydraulic Flow
Not Published
Not Published
No. of Standard Remote Valves
Rear: 0 (loader: 2)
None standard (1 spool optional)
No. of Optional Remote Valves
Up to 4
1 spool
Fuel Tank Capacity
7.1 gal
14.55 gal
Coolant Capacity
5.8 qt
Not Published
Crankcase Capacity
4.8 qt
Not Published
Transmission / Hydraulic System Capacity
9.8 gal
Not Published
Front Axle Fluid Capacity
6.8 qt
Not Published
PTO Type
Independent
Live
PTO Rear
540 rpm
540 rpm @ 2058 engine rpm
Mid-PTO Availability
Not Published
Not Published
Category, 3-Point Hitch
Category I
Category I & II adjustable, with telescopic stabilizers
Hitch Lift Capacity
3,306 lb
3525 lb
Hitch Lift Capacity (at 24”)
2,425 lb
Not Published
Lift Control Type
Position control
Position & draft control
Transmission Type
HST (hydrostatic)
Sliding mesh
No. of Speeds
3-range hydrostatic
8F / 2R
Max Travel Speed (Forward)
18 mph
Not Published
Max Travel Speed (Reverse)
17.95 mph
Not Published
Clutch
Not Published
Dual
Differential Lock & Limited Slip Options
Differential lock (standard)
Not Published
Frame Type
Not Published
Not Published
Steering
Hydrostatic
Hydrostatic power steering
Brakes
Wet, multi-disc
Fully enclosed dry disc
Seat Suspension & Adjustability
Suspension seat
mComfort mechanical suspension seat
Front Axle Type
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Overall Length with 3-Point Hitch
120.9 in
115.3 in
Overall Width
55.6 in
69.4 in
Wheelbase
65.7 in
Not Published
Ground Clearance
13.1 in
Not Published
Min. Turn Radius without Brakes
124.8 in (left); 121.3 in (right)
9.7 ft (with brake applied)
Height to Top of ROPS
Not Published
88 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
89.3 in
Not Published
Tractor Weight (Base)
3,644 lb
4191 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
4,652 lb
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 Agricultural
R1 Agricultural - Front
7-16
6X16
R1 Agricultural - Rear
11.2-24
12.4X28
R3 Turf - Front
27x8.5-15, 6PR
Not Published
R3 Turf - Rear
41x14.00, 4PR
Not Published
R4 Industrial - Front
25x8.5-14, 6PR
Not Published
R4 Industrial - Rear
380/70-19.5, 6PR (standard); 15-19.5 (option)
Not Published
Quick Attach Loader System
BL150C: quick attachment assembly
Skid-steer style quick-attach coupler
Loader Model
BL150C
4550-2L
Loader Lift Height
BL150C: 104.9 in
4550-2L: 116.6 in
Loader Lift Capacity (Full Height)
BL150C: 2,200 lb
4550-2L: 2,866 lb at pivot pins to full height
Loader Breakout Force
BL150C: 3,422 lb
4550-2L: 4,978 lb at pivot pins
Warranty Length & Coverage
Bumper-to-bumper 24 months or 2,000 hours (parts and labor); powertrain 72 months or 3,000 hours for non-commercial use (36 months or 2,000 hours rental and commercial); loaders and backhoes 12 months
