▶ EngineEngine Manufacturer Kukje LS Engine Model A2300N2 L3C19-T Engine Type Diesel, liquid-cooled 3-cylinder, liquid-cooled, diesel, naturally aspirated, CRDI No. of Cylinders 4 3 Displacement 139 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Not Published 34 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Not Published Dry Fuel System Not Published CRDI (Delphi common rail direct injection) Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump, engine driven Implement Flow 8.9 gpm 8.2 gpm Steering Flow Not Published 5.5 gpm Total Hydraulic Flow 13.2 gpm 13.7 gpm Overall Hydraulic Pump Flow Not Published 13.7 gpm Hydraulic System Type Open center Open center system, position control Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 0 No. of Optional Remote Valves Up to 2 1 or 2 pairs (optional) ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 7.4 gal Coolant Capacity 9.8 qt 1.9 gal Crankcase Capacity 6 qt 1.5 gal Transmission / Hydraulic System Capacity 9.7 gal 8.5 gal Front Axle Fluid Capacity Not Published 1.7 gal ▶ PTO & HitchPTO Type Live (2-stage clutch) Independent (wet disc clutch) PTO Rear 540 / 1000 rpm Standard (540 rpm) Mid-PTO Availability Not Published Optional (2,000 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,580 lb 1,808 lb Hitch Lift Capacity (at 24”) Not Published 1,433 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchromesh Synchro Shuttle No. of Speeds 12F/12R F12 x R12 Max Travel Speed (Forward) Not Published 14.33 mph Max Travel Speed (Reverse) Not Published 13.63 mph Clutch Not Published Dry single clutch Differential Lock & Limited Slip Options Not Published Mechanical pedal type ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Front wheel mechanical assist (4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 127 in 121 in Overall Width 61 in 54 in (R1); 66 in (R4) Wheelbase 71 in 69 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes Not Published 10.79 ft (left); 11.02 ft (right) Height to Top of ROPS 88 in 88 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,883 lb 2,881 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear; Turf: 29x12.00-15 front / 44x18.00-20 rear; Industrial: 12-16.5 front / 17.5L-24 rear R1 agricultural, R4 industrial or R3 turf at no extra cost R1 Agricultural - Front 8-18 7-14 R1 Agricultural - Rear 12.4-28 11.2-24 R3 Turf - Front 29x12.00-15 25x8.50-14 R3 Turf - Rear 44x18.00-20 41x14-20 R4 Industrial - Front 12-16.5 25x8.50-14 R4 Industrial - Rear 17.5L-24 43x16-20 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model BL20 LL3302 Loader Lift Height BL20: 103 in LL3302: 94 in Loader Lift Capacity (Full Height) BL20: 2,094 lb LL3302: 2,153 lb (at pivot pin, full height) Loader Breakout Force BL20: 2,755 lbf (at 19.7 in reach, not pivot pin) (19.7 in forward of pivot pin) LL3302: 3,579 lb (at pivot pin) ▶ WarrantyWarranty Length & Coverage Not Published 6-year limited warranty
