▶ EngineEngine Manufacturer Kukje LS Engine Model A2300N2 L3C19-T4 Engine Type Diesel, liquid-cooled 4-stroke, vertical, water cooling, CRDI No. of Cylinders 4 3 Displacement 139 in³ 114.7 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 40 hp 40 hp PTO Power Not Published 34.4 hp Engine Emissions Constraints Not Published Not Published Cooling System Type Liquid-cooled Water-cooled Air Cleaner Not Published Dry Fuel System Not Published Delphi CRDI (Common Rail Direct Injection) Alternator 45 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Not Published Gear pump type, engine drive Implement Flow 8.9 gpm 8.2 gpm Steering Flow Not Published 4.1 gpm (mechanical); 5.5 gpm (HST) Total Hydraulic Flow 13.2 gpm 12.3 gpm Overall Hydraulic Pump Flow Not Published Not Published Hydraulic System Type Open center Not Published Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 0 2 No. of Optional Remote Valves Up to 2 Not Published ▶ Fluid CapacityFuel Tank Capacity 11.1 gal 10.6 gal (roll-bar); 12.4 gal (cabin) Coolant Capacity 9.8 qt 2.3 gal Crankcase Capacity 6 qt 1.6 gal Transmission / Hydraulic System Capacity 9.7 gal 11.4 gal Front Axle Fluid Capacity Not Published 2.1 gal ▶ PTO & HitchPTO Type Live (2-stage clutch) Independent PTO with wet disk clutch PTO Rear 540 / 1000 rpm 540 (standard); 540 / 750 / 1,000 (optional 3-speed) Mid-PTO Availability Not Published Yes, 2000 rpm mid-PTO Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,580 lb 2,756 lb Hitch Lift Capacity (at 24”) Not Published 2,469 lb Lift Control Type Not Published Position and draft control ▶ Transmission & DrivetrainTransmission Type Synchromesh Synchro-shuttle (mechanical) No. of Speeds 12F/12R F16 x R16 (F32 x R16 with creeper, optional) Max Travel Speed (Forward) Not Published 16.8 mph Max Travel Speed (Reverse) Not Published 15.3 mph Clutch Not Published Dry single clutch (mechanical only) Differential Lock & Limited Slip Options Not Published Mechanical pedal type differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic power steering Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type 4WD (MFWD) Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 127 in 133 in Overall Width 61 in 62.5 in Wheelbase 71 in 73.2 in Ground Clearance 12.2 in Not Published Min. Turn Radius without Brakes Not Published 9.5 ft (with brake applied) Height to Top of ROPS 88 in 93 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published 92 in ▶ WeightTractor Weight (Base) 3,883 lb Roll-bar: 3,770 lb; Cabin: 4,210 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options Agricultural: 8-18 front / 12.4-28 rear; Turf: 29x12.00-15 front / 44x18.00-20 rear; Industrial: 12-16.5 front / 17.5L-24 rear Ag 9.5-16 / 13.6-24; Turf 28x8.5-15 / 41x14-20; Industrial 12-16.5 / 17.5L-24 R1 Agricultural - Front 8-18 9.5-16 (6PR) R1 Agricultural - Rear 12.4-28 13.6-24 (8PR) R3 Turf - Front 29x12.00-15 28x8.5-15 R3 Turf - Rear 44x18.00-20 41x14-20 R4 Industrial - Front 12-16.5 12-16.5 R4 Industrial - Rear 17.5L-24 17.5L-24 ▶ Loader & AttachmentsQuick Attach Loader System Not Published Not Published Loader Model BL20 LL4104 Loader Lift Height BL20: 103 in LL4104: 96.3 in Loader Lift Capacity (Full Height) BL20: 2,094 lb LL4104: 2,713 lb Loader Breakout Force BL20: 2,755 lbf (at 19.7 in reach, not pivot pin) (19.7 in forward of pivot pin) LL4104: 3,802 lb ▶ WarrantyWarranty Length & Coverage Not Published 6-year / 1,500-hour limited powertrain warranty; 2-year / 750-hour bumper-to-bumper warranty
