▶ EngineEngine Manufacturer Yanmar TYM Engine Model 3TNV74F T1100N2 Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 60.6 in³ 71.7 in³ Rated Engine Speed 3000 rpm 2850 rpm Engine Power (Gross) 19 hp 24 hp PTO Power 14.6 hp 21 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Not Published Air Cleaner Single dry Dry element Fuel System IDI IDI Alternator 40 A, 12 V 60 A, 12 V ▶ HydraulicsPump Type Single gear pump Dual gear pump Implement Flow 4.17 gpm 4.7 gpm Steering Flow 2.11 gpm 3.3 gpm Total Hydraulic Flow 6.28 gpm 7.9 gpm Overall Hydraulic Pump Flow 6.28 gpm 7.9 gpm Hydraulic System Type Open center Dual gear pump Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published None No. of Optional Remote Valves 1 2 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.0 gal Coolant Capacity 3.7 qt 5.3 qt Crankcase Capacity 2.1 qt 2.9 qt Transmission / Hydraulic System Capacity 3.6 gal 3.7 gal Front Axle Fluid Capacity 2.6 qt 3.5 qt ▶ PTO & HitchPTO Type Independent Live PTO Rear 540 rpm 540/1000 rpm Mid-PTO Availability Available Available Category, 3-Point Hitch Category I (Narrow) Category I Hitch Lift Capacity 1,100 lb 1,499 lb Hitch Lift Capacity (at 24”) 679 lb 974 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST 2400R: Constant Mesh; 2400H: HST No. of Speeds 2 Range 2400R: F6 x R2; 2400H: 2-Range Max Travel Speed (Forward) 7.8 mph 2400R: 9.9 mph; 2400H: 12.1 mph Max Travel Speed (Reverse) Not Published 2400R: 3.9 mph; 2400H: 12.1 mph Clutch Not Published Dry single plate Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet, Multi disc Seat Suspension & Adjustability Not Published Comfortable suspension seat Front Axle Type Not Published 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.2 in Wheelbase 53.1 in 59.1 in Ground Clearance 8.3 in 12.1 in Min. Turn Radius without Brakes 86.6 in (L) 9.6 ft; (R) 9.5 ft Height to Top of ROPS 86.6 in 87.3 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) 120.3 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,433 lb 2400R: 1,792 lb; 2400H: 1,829 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front BAR F 16x6.50-8 6-12 R1 Agricultural - Rear BAR R 24x12.00-12 9.5-16 R3 Turf - Front 16x7.50-8 23x8.50-12 R3 Turf - Rear 24x12.00-12 33x12.50-16.5 R4 Industrial - Front 16x7.50-8 23x8.50-12 R4 Industrial - Rear 24x12.00-12 12-16.5 ▶ Loader & AttachmentsQuick Attach Loader System TX19H: Quick attach mechanism BL100S: Quick attach mechanism Loader Model TX19H BL100S Loader Lift Height TX19H: 71.3 in BL100S: 88.3 in Loader Lift Capacity (Full Height) TX19H: 617 lb BL100S: 1,314 lb (at pivot pin) Loader Breakout Force TX19H: 1,235 lb (at pivot pin, ground level) BL100S: 1,960 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit None tagged yet
