TYM 2400 vs TYM T194
Every published spec for both machines, side by side. The verdict below is computed straight from the spec sheets, not opinion.
Across 9 measurable specs, the TYM 2400 leads 9 categories to 0. Machine pages: TYM 2400 and TYM T194.
Want a third or fourth machine in the mix? Open this matchup in the comparison tool and add up to two more.
Category Verdict
| Spec | TYM 2400 | TYM T194 |
|---|---|---|
| Engine HP (hp) | ▲ 24 hp | 19 hp |
| PTO HP (hp) | ▲ 21 hp | 14.6 hp |
| Weight (lb) | ▲ 1,829 lb | 1,433 lb |
| Loader Lift (lb) | ▲ 1,314 lb | 617 lb |
| 3-Pt Lift (24 in) (lb) | ▲ 974 lb | 679 lb |
| Lift Height (in) | ▲ 88.3 in | 71.3 in |
| Breakout Force (lbf) | ▲ 1,960 lbf | 1,235 lbf |
| Hydraulic Flow (gpm) | ▲ 7.9 gpm | 6.3 gpm |
| Travel Speed (mph) | ▲ 12.1 mph | 7.8 mph |
Full Spec Sheet
Every published spec, side by side, including the details the graphs above don't chart.
| Spec | TYM2400 | TYMT194 |
|---|
| Engine Manufacturer | TYM | Yanmar |
|---|---|---|
| Engine Model | T1100N2 | 3TNV74F |
| Engine Type | 3-cylinder, naturally aspirated diesel | 3-cylinder, naturally aspirated diesel |
| No. of Cylinders | 3 | 3 |
| Displacement | 71.7 in³ | 60.6 in³ |
| Rated Engine Speed | 2850 rpm | 3000 rpm |
| Engine Power (Gross) | 24 hp | 19 hp |
| PTO Power | 21 hp | 14.6 hp |
| Engine Emissions Constraints | Tier 4 | Tier 4 |
| Cooling System Type | Not Published | Water-cooled |
| Air Cleaner | Dry element | Single dry |
| Fuel System | IDI | IDI |
| Alternator | 60 A, 12 V | 40 A, 12 V |
TYM 2400 vs TYM T194: Quick Answers
- Which has more horsepower, the TYM 2400 or the TYM T194?
- The TYM 2400 leads on engine hp at 24 hp hp, compared to 19 hp hp for the TYM T194.
- Which has more PTO horsepower, the TYM 2400 or the TYM T194?
- The TYM 2400 leads on pto hp at 21 hp hp, compared to 14.6 hp hp for the TYM T194.
- Which is heavier, the TYM 2400 or the TYM T194?
- The TYM 2400 leads on weight at 1,829 lb lb, compared to 1,433 lb lb for the TYM T194.
- Which has more loader lift capacity, the TYM 2400 or the TYM T194?
- The TYM 2400 leads on loader lift at 1,314 lb lb, compared to 617 lb lb for the TYM T194.
- Which has more three-point hitch lift capacity, the TYM 2400 or the TYM T194?
- The TYM 2400 leads on 3-pt lift (24 in) at 974 lb lb, compared to 679 lb lb for the TYM T194.
