▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV74F 3TNV74F Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated diesel No. of Cylinders 3 3 Displacement 60.6 in³ 60.6 in³ Rated Engine Speed 3000 rpm 3200 rpm Engine Power (Gross) 19 hp 21.5 hp PTO Power 14.6 hp 15.1 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Water-cooled Water-cooled Air Cleaner Single dry Single dry Fuel System IDI IDI Alternator 40 A, 12 V 40 A, 12 V ▶ HydraulicsPump Type Single gear pump Single gear pump Implement Flow 4.17 gpm 4.6 gpm Steering Flow 2.11 gpm 2.1 gpm Total Hydraulic Flow 6.28 gpm 6.7 gpm Overall Hydraulic Pump Flow 6.28 gpm 6.7 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves 1 1 ▶ Fluid CapacityFuel Tank Capacity 6.6 gal 6.6 gal Coolant Capacity 3.7 qt 3.7 qt Crankcase Capacity 2.1 qt 1.9 qt Transmission / Hydraulic System Capacity 3.6 gal 3.6 gal Front Axle Fluid Capacity 2.6 qt 2.6 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available Available Category, 3-Point Hitch Category I (Narrow) Category I (Narrow) Hitch Lift Capacity 1,100 lb 1,100 lb Hitch Lift Capacity (at 24”) 679 lb 679 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type HST HST No. of Speeds 2 Range 2 Range Max Travel Speed (Forward) 7.8 mph 8.4 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet disc Seat Suspension & Adjustability Not Published Not Published Front Axle Type Not Published 4WD center-pivot, reverse Eliot type Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 44.5 in 44.5 in Wheelbase 53.1 in 53.1 in Ground Clearance 8.3 in 8.3 in Min. Turn Radius without Brakes 86.6 in 86.6 in Height to Top of ROPS 86.6 in 86.6 in Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published Overall Length 94.2 in (with 3-point hitch) 94.2 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 1,433 lb 1,472 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front BAR F 16x6.50-8 BAR F 16x6.50-8 R1 Agricultural - Rear BAR R 24x12.00-12 BAR R 24x12.00-12 R3 Turf - Front 16x7.50-8 Turf Master 16x7.50-8 NHS TL 4PR R3 Turf - Rear 24x12.00-12 Turf Master 24x12.00-12 NHS TL 4PR R4 Industrial - Front 16x7.50-8 WT300 18x8.5-10 NHS TL 4PR R4 Industrial - Rear 24x12.00-12 WT300 26x12.00-12 NHS TL 4PR ▶ Loader & AttachmentsQuick Attach Loader System TX19H: Quick attach mechanism TX22H: Quick attach mechanism Loader Model TX19H TX22H Loader Lift Height TX19H: 71.3 in TX22H: 71.3 in Loader Lift Capacity (Full Height) TX19H: 617 lb TX22H: 617 lb (at pivot pin) Loader Breakout Force TX19H: 1,235 lb (at pivot pin, ground level) TX22H: 1,235 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Not Published Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months
