▶ EngineEngine Manufacturer Yanmar Yanmar Engine Model 3TNV80F-NXDKTFX 3TNV80F Engine Type 3-cylinder, naturally aspirated diesel 3-cylinder, naturally aspirated, liquid-cooled diesel No. of Cylinders 3 3 Displacement 77.3 in³ 77.3 in³ Rated Engine Speed 3000 rpm 3000 rpm Engine Power (Gross) 24.7 hp 24.7 hp PTO Power 18.3 hp 17.2 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Not Published Pressurized liquid with recirculating bypass Air Cleaner Single dry Single-element Fuel System IDI In-line injection pump, indirect injection (swirl chamber) Alternator 40 A, 12 V 50 A ▶ HydraulicsPump Type Single gear pump Gear Implement Flow 4.17 gpm 4.6 gpm Steering Flow 2.77 gpm 2.1 gpm Total Hydraulic Flow 6.94 gpm 6.7 gpm Overall Hydraulic Pump Flow 6.94 gpm 6.7 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published 1 ▶ Fluid CapacityFuel Tank Capacity 8.4 gal 6.6 gal Coolant Capacity 0.95 gal 3.49 qt Crankcase Capacity Not Published 3 qt Transmission / Hydraulic System Capacity 4.49 gal 3.3 gal Front Axle Fluid Capacity 1.18 gal 0.5 gal ▶ PTO & HitchPTO Type Independent Independent, electro-hydraulic engagement PTO Rear 540 rpm 540 rpm Mid-PTO Availability Available (Mid-PTO kit) Standard (2,500 rpm) Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 1,550 lb 992 lb Hitch Lift Capacity (at 24”) 560 lb 728 lb Lift Control Type Position control Lift-hold-lower ▶ Transmission & DrivetrainTransmission Type HST 2-range hydrostatic, dual pedal No. of Speeds 2 Infinite (2 ranges) Max Travel Speed (Forward) 13.57 mph 9.1 mph Max Travel Speed (Reverse) Not Published 5.5 mph Clutch Not Published Not Published Differential Lock & Limited Slip Options Differential lock Mechanical, foot-operated rear differential lock ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Hydraulic Hydrostatic power steering Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Mechanical suspension seat Deluxe high-back seat with armrests and adjustable backrest Front Axle Type Four-wheel drive (standard) 4WD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 56.29 in 46.7 in Wheelbase 61.02 in 56.1 in Ground Clearance 10.23 in 12 in Min. Turn Radius without Brakes 110.23 in 94 in Height to Top of ROPS 85.94 in 87.4 in Height to Top of ROPS (folded) Not Published 64 in Height to Top of Cab Model Not Published 87.4 in Overall Length 105.11 in (with 3-point hitch) 97.4 in ▶ WeightTractor Weight (Base) 2,207 lb ROPS: 1,444 lb; Cab: 1,805 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R3 Turf, R4 Industrial, Hybrid R3 Turf, R4 Industrial R1 Agricultural - Front Not Published Not Published R1 Agricultural - Rear Not Published Not Published R3 Turf - Front 23x8.5-12 18x8.50-10 R3 Turf - Rear 33x12.5-16.5 26x12.0-12 R4 Industrial - Front 23x8.5-14 18x8.50-10 R4 Industrial - Rear 14-17.5 26x12.0-12 ▶ Loader & AttachmentsQuick Attach Loader System L2025P: Quick attach mechanism 100LC: Quick Mount system, no tools needed Loader Model L2025P 100LC Loader Lift Height L2025P: 87.7 in 100LC: 72 in (at pivot pin) Loader Lift Capacity (Full Height) L2025P: 1,380 lb (at pivot pin) 100LC: 1,005 lb (at bucket pivot pin, max height) Loader Breakout Force L2025P: 2,059 lb (at pivot pin, ground level) 100LC: 2,078 lb (at bucket pivot pin) ▶ WarrantyWarranty Length & Coverage Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months Basic 2 years or 750 hours; powertrain to 6 years or 1,500 hours total
