Pick up to 4tractors and we'll lay every spec sheet out side by side. Same data we publish on the individual model pages, stacked in columns so you can compare numbers at a glance.
No photo
—
TYMT3025C
No photo
—
TYMT254
Comparison loaded for 2 tractors.
Spec
TYMT3025C
TYMT254
PTO Power
21 hp (15.7 kW)
18.8 hp (14.0 kW)
Alternator
12 V, 70 A
12 V, 40 A
Air Cleaner
Dry element
Single dry
Engine Type
3-cylinder, naturally aspirated diesel
3-cylinder, naturally aspirated diesel
Fuel System
IDI
IDI
Displacement
104.5 in³ (1,714 cc)
77.3 in³ (1267 cc)
No. of Cylinders
3
3
Rated Engine Speed
2,100 rpm
3,000 rpm
Cooling System Type
Not Published
Water-cooled
Engine Manufacturer
TYM
Yanmar
Engine Emissions Constraints
Tier 4
Tier 4
Engine Power (Gross vs. Net HP)
Gross: 24 hp (18 kW)
Gross: 23.9 hp (17.8 kW)
Tractor Weight with Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
Not Published
Weight with ROPS and Loader
Not Applicable
Not Published
Pump Type
Dual gear pump
Single gear pump
Steering Flow
15.8 L/min (4.2 gpm)
10.5 L/min (2.8 gpm)
Implement Flow
29.3 L/min (7.7 gpm)
15.8 L/min (4.2 gpm)
Total Hydraulic Flow
45.1 L/min (11.9 gpm)
26.3 L/min (6.9 gpm)
Hydraulic System Type
Open center
Open center
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
45.1 L/min (11.9 gpm)
26.3 L/min (6.9 gpm)
No. of Optional Remote Valves
Not Published
1
No. of Standard Remote Valves
Loader: 4; Rear: 0
0
R3 Turf - Rear
Not Applicable
29x12.50-15
R3 Turf - Front
Not Applicable
20x8.00-10
Tire Size & Options
R1 Agricultural, Golf Tires, R4 Industrial
R1 Agricultural, R3 Turf, R4 Industrial; R4 Lg Industrial (optional)
R4 Industrial - Rear
380/70-19.5, 6PR
27x12.5-15; 12-16.5
R4 Industrial - Front
Not Published
20x8.00-10; 23x8.50-12
R1 Agricultural - Rear
11.2-24, 8PR
9.5-16
R1 Agricultural - Front
7-16, 6PR
6.0-12
PTO Rear
540 rpm
540 rpm
PTO Type
Independent
Independent
Lift Control Type
Position control
Position control
Hitch Lift Capacity
3,306 lb (1,500 kg)
1,214 lb (551 kg)
Mid-PTO Availability
Not Published
Available
Category, 3-Point Hitch
Category I
Category I (Narrow)
Hitch Lift Capacity (at 24”)
2,425 lb (1,100 kg)
1,101 lb (499 kg)
Rear 3-Point Hitch Lift Capacity
3,306 lb (1,500 kg)
1,214 lb (551 kg)
Coolant Capacity
5.3 qt (5.0 L)
3.8 qt (3.6 L)
Crankcase Capacity
4.5 qt (4.3 L)
2.9 qt (2.7 L)
Fuel Tank Capacity
7.1 gal (27.0 L)
5.8 gal (22 L)
Front Axle Fluid Capacity
6.8 qt (6.4 L)
3.7 qt (3.5 L)
Transmission / Hydraulic System Capacity
9.8 gal (37.0 L)
3.7 gal (14 L)
Loader Lift Height
104.9 in (2,665 mm)
75 in (1905 mm)
Loader Breakout Force
3,422 lb (1,552 kg)
1,680 lb (720 kg)
Price for Backhoe Option
BH70
TB60
Price for Mid-Mount Mower
Not Published
MM60R
Quick Attach Loader System
L3048: Quick attach mechanism
TX25P: Quick attach mechanism
Loader Lift Capacity (Full Height)
2,200 lb (998 kg)
948 lb (430 kg)
Clutch
Not Applicable
Not applicable
No. of Speeds
3-range
Infinite 2-Range
Transmission Type
Hydrostatic (HST)
HST
Max Travel Speed (Forward)
14.6 mph (23.6 km/h)
11.0 mph (17.7 km/h)
Max Travel Speed (Reverse)
Not Published
Not Published
Differential Lock & Limited Slip Options
Not Published
Differential lock
Brakes
Wet, multi-disc
Wet disc
Steering
Hydrostatic
Hydrostatic
Frame Type
Not Published
Not Published
Front Axle Type
Not Published
Not Published
Drawbar Capacity
Not Published
Not Published
Front Axle Rating
Not Published
Not Published
Seat Suspension & Adjustability
Not Published
Ergonomic seating
Wheelbase
65.7 in (1,670 mm)
57.5 in (1460 mm)
Overall Width
55.6 in (1,413 mm)
45.8 in (1164 mm)
Ground Clearance
13.1 in (334 mm)
9.4 in (240 mm)
Height to Top of ROPS
Not Applicable
91.3 in (2320 mm)
Height to Top of Cab Model
89.3 in (2,267 mm)
Not Published
Height to Top of ROPS (folded)
Not Applicable
Not Published
Min. Turn Radius without Brakes
L: 105.51 in (2,680 mm); R: 104.72 in (2,660 mm)
100 in (2540 mm)
Overall Length with 3-Point Hitch
120.9 in (3,071 mm)
100.5 in (2553 mm)
Financing Options
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
0% financing for up to 72 months and instant cash rebates. Contact dealer for more information.
Base Price with Loader
Not Published
Not Published
Warranty Length & Coverage
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
Up to 2 years or until the 2,000 hours mark, bumper-to-bumper warranty; 3000 hours maximum coverage period for parts and labour on drivetrains or powertrains; 12-months warranty period for implements, including loaders and backhoes.
