▶ EngineEngine Manufacturer TYM John Deere Engine Model T2300N2 PowerTech 3029T Engine Type 4-cylinder, naturally aspirated diesel Diesel, turbocharged, liquid-cooled No. of Cylinders 4 3 Displacement 139.5 in³ 179 in³ Rated Engine Speed 2600 rpm 2100 rpm Engine Power (Gross) 48.3 hp 48 hp PTO Power 35.9 hp 36.6 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Single dry Two paper elements Fuel System IDI Not Published Alternator 70 A, 12 V 40 A ▶ HydraulicsPump Type Dual gear pump Not Published Implement Flow 7.7 gpm 11.4 gpm Steering Flow 4.2 gpm 6.8 gpm Total Hydraulic Flow 11.9 gpm 18.2 gpm Overall Hydraulic Pump Flow 11.9 gpm 18.2 gpm Hydraulic System Type Open center Open Center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 (double rear remote with detent, accessory) 2 ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 18.0 gal Coolant Capacity 6.9 qt 10 qt Crankcase Capacity 6.8 qt 9 qt Transmission / Hydraulic System Capacity 8.5 gal 10.3 gal Front Axle Fluid Capacity 8.7 qt 4.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540 rpm Mid-PTO Availability Optional (Mid-PTO kit accessory) Not Published Category, 3-Point Hitch Category I Category II, convertible to I Hitch Lift Capacity 2,689.6 lb Not Published Hitch Lift Capacity (at 24”) 1,764 lb 3,192 lb Lift Control Type Position control Position control with top link draft sensing ▶ Transmission & DrivetrainTransmission Type Mechanical synchro shuttle SyncShuttle No. of Speeds 12 forward / 12 reverse 9F/3R Max Travel Speed (Forward) 14.9 mph Not Published Max Travel Speed (Reverse) Not Published Not Published Clutch Dry single plate Dry Differential Lock & Limited Slip Options Differential lock (pedal) Mechanical, rear ▶ Chassis, Steering & ControlsFrame Type Unitized: transmission case, clutch housing, engine and front axle support bolted into a rigid unit Not Published Steering Hydrostatic Hydrostatic power steering Brakes Wet disc Hydraulic wet disc brakes Seat Suspension & Adjustability Fore and aft sliding seat with cushion strength adjustment Not Published Front Axle Type 4WD center-pivot, reverse Elliott type 2WD or MFWD Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 131 in 137.8 in Overall Width 54.5 in 57.3 in Wheelbase 69.7 in 80.7 in Ground Clearance 12.8 in 2WD: 18.8 in; MFWD: 13.4 in Min. Turn Radius without Brakes 117.5 in 138 in Height to Top of ROPS 94.5 in 93.9 in Height to Top of ROPS (folded) Not Published 75.7 in Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,289 lb 2WD: 4,414 lb; MFWD: 5,401 lb Weight with ROPS and Loader 4,310 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial Not Published R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR (standard); Farm Specialist 7-16 NHS TL 6PR (option) 2WD: 7.5-16; MFWD: 9.5-24 R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) 13.6-28 R3 Turf - Front Multi-Trac CS 27x10.5-15 NHS TL 4PR (standard); Multi-Trac CS 27x8.50-15 NHS TL 4PR (option) 9.5-16 R3 Turf - Rear 12.5x20 (standard); Multi-Trac CS 41x14.00-20 NHS TL 4PR (option) 21.5L-16.1 R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR 12.5/80-18 R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR 16.9-24 ▶ Loader & AttachmentsQuick Attach Loader System TX47: skid steer type quick attach (TX47-E: Euro type) H240 (NSL or MSL) Loader Model TX47 H240NSL Loader Lift Height TX47: 105.6 in 131 in Loader Lift Capacity (Full Height) TX47: 2,152 lb 3,671 lb Loader Breakout Force TX47: 3,198 lb 4,504 lb ▶ WarrantyWarranty Length & Coverage Bumper-to-bumper 24 months or 2,000 hours (parts and labor); powertrain 72 months or 3,000 hours for non-commercial use (36 months or 2,000 hours rental and commercial); loaders and backhoes 12 months Not Published ▶ ITC Company AccessoriesAccessories that fit None tagged yet
