Transmission case, clutch, clutch housing, engine and front axle support bolted together to form a rigid unit
Folding ROPS; ComfortGard cab optional; four-wheel drive standard
Steering
Hydrostatic
Power steering
Brakes
Wet disc
Wet disk
Seat Suspension & Adjustability
Fore and aft sliding seat with cushion strength adjustment
Air ride seat optional
Front Axle Type
4WD center-pivot, reverse Elliott type
Mechanical front wheel drive (MFWD), standard, all ranges
Front Axle Rating
Not Published
3,528 lb
Drawbar Capacity
Not Published
1,103 lb
Overall Width
54.5 in
65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires)
Wheelbase
69.7 in
71.5 in
Ground Clearance
12.8 in
Not Published
Min. Turn Radius without Brakes
117.5 in
Not Published
Height to Top of ROPS
Not Published
97.2 in
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
92.5 in
92.4 in
Overall Length
131 in (with 3-point hitch)
128.2 in (with 3-point hitch)
Tractor Weight (Base)
3,607 lb
3,700 lb (open station); 4,345 lb (cab)
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
4,628 lb (3,607 + 1,021, computed; TX47 loader with bucket)
Not Published
Tire Size & Options
R1 Agricultural, R3 Turf, R4 Industrial
R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear
Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months
3-year / 2,000-hour limited warranty (as sold new)
