Folding ROPS; ComfortGard cab optional; four-wheel drive standard
Transmission case, clutch, clutch housing, engine and front axle support bolted together to form a rigid unit
Steering
Power steering
Hydrostatic
Brakes
Wet disk
Wet disc
Seat Suspension & Adjustability
Air ride seat optional
Fore and aft sliding seat with cushion strength adjustment
Front Axle Type
Mechanical front wheel drive (MFWD), standard, all ranges
4WD center-pivot, reverse Elliott type
Front Axle Rating
3,528 lb
Not Published
Drawbar Capacity
1,103 lb
Not Published
Overall Width
65.6 in (minimum, R1 tires); 89.1 in (maximum, R1 tires)
54.5 in
Wheelbase
71.5 in
69.7 in
Ground Clearance
Not Published
12.8 in
Min. Turn Radius without Brakes
Not Published
117.5 in
Height to Top of ROPS
97.2 in
Not Published
Height to Top of ROPS (folded)
Not Published
Not Published
Height to Top of Cab Model
92.4 in
92.5 in
Overall Length
128.2 in (with 3-point hitch)
131 in (with 3-point hitch)
Tractor Weight (Base)
3,700 lb (open station); 4,345 lb (cab)
3,607 lb
Weight with ROPS and Loader
Not Published
Not Published
Weight with Cab and Loader
Not Published
4,628 lb (3,607 + 1,021, computed; TX47 loader with bucket)
Tire Size & Options
R1 8.00-16 front and 13.6-28 rear; R3 27x10.5-15 front and 44x18.00-20 rear; R4 10.00-16.5 front and 17.5L-24 rear; golf 27x12LL-15 front and 22.5LL-16.1 rear
3-year / 2,000-hour limited warranty (as sold new)
Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months
