▶ EngineEngine Manufacturer TYM TYM Engine Model T2300N2 T2300N2 Engine Type 4-cylinder, naturally aspirated diesel 4-cylinder, naturally aspirated diesel No. of Cylinders 4 4 Displacement 139.5 in³ 139.5 in³ Rated Engine Speed 2600 rpm 2600 rpm Engine Power (Gross) 48.3 hp 48 hp PTO Power 35.4 hp 38.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid-cooled Liquid-cooled Air Cleaner Single dry Dry element Fuel System IDI IDI (indirect injection) Alternator 70 A, 12 V 70 A, 12 V ▶ HydraulicsPump Type Dual gear pump Dual gear pump Implement Flow 7.7 gpm 11.4 gpm Steering Flow 4.2 gpm 5.2 gpm Total Hydraulic Flow 11.9 gpm 16.5 gpm Overall Hydraulic Pump Flow 11.9 gpm 16.5 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 4 No. of Optional Remote Valves Double rear remote with detent (accessory) Not Published ▶ Fluid CapacityFuel Tank Capacity 9.0 gal 11.8 gal Coolant Capacity 6.9 qt 8.3 qt Crankcase Capacity 6.8 qt 4.8 qt Transmission / Hydraulic System Capacity 8.5 gal 4820C: 10.3 gal; 4820CH: 11.1 gal Front Axle Fluid Capacity 8.7 qt 6.8 qt ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540 rpm 540/750 rpm Mid-PTO Availability Optional (Mid-PTO kit accessory) Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,690 lb 3,306 lb Hitch Lift Capacity (at 24”) 1,764 lb 2,425 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Mechanical 4820C: Synchromesh; 4820CH: HST No. of Speeds 12 forward / 12 reverse 4820C: F16 x R16; 4820CH: 4-Range Max Travel Speed (Forward) 14.9 mph 4820C: 16 mph; 4820CH: 19.5 mph Max Travel Speed (Reverse) Not Published 4820C: 15.2 mph; 4820CH: 19.5 mph Clutch Dry single plate 4820C: Dry single type; 4820CH: N/A (HST) Differential Lock & Limited Slip Options Differential lock (pedal) Standard differential lock ▶ Chassis, Steering & ControlsFrame Type Transmission case, clutch, clutch housing, engine and front axle support bolted together to form a rigid unit Not Published Steering Hydrostatic Hydrostatic Brakes Wet disc Wet, multi-disc Seat Suspension & Adjustability Fore and aft sliding seat with cushion strength adjustment Suspension seat Front Axle Type 4WD center-pivot, reverse Elliott type 4WD (selectable 2WD/4WD) Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Width 54.5 in 64.9 in Wheelbase 69.7 in 71.1 in Ground Clearance 12.8 in 15.5 in Min. Turn Radius without Brakes 117.5 in L: 128.7 in; R: 126.0 in Height to Top of ROPS Not Published Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model 92.5 in 97 in Overall Length 131 in (with 3-point hitch) 127.4 in (with 3-point hitch) ▶ WeightTractor Weight (Base) 3,607 lb 4,349 lb Weight with ROPS and Loader Not Published Not Published Weight with Cab and Loader 4,628 lb (3,607 + 1,021, computed; TX47 loader with bucket) Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R1 Agricultural - Front Farm Specialist 8.0-16 NHS TL 6PR (standard); Farm Specialist 7-16 NHS TL 6PR (option) 9.5-16 R1 Agricultural - Rear Farm Specialist 12.4-24 NHS TL 6PR (standard); Farm Specialist 11.2-24 NHS TL 6PR (option) 13.6-26 R3 Turf - Front Multi-Trac CS 27x10.5-15 NHS TL 4PR (standard); Multi-Trac CS 27x8.50-15 NHS TL 4PR (option) 27x8.5-15 / 29x12.5-15 R3 Turf - Rear 12.5x20 (standard); Multi-Trac CS 41x14.00-20 NHS TL 4PR (option) 41x14-20 / 44x18-20 R4 Industrial - Front Trac Chief 10-16.50 NHS TL 6PR 12-16.5 R4 Industrial - Rear Xtra Grip 43x16.00-20 NHS TL 6PR 17.5Lx24 ▶ Loader & AttachmentsQuick Attach Loader System TX47: Quick attach mechanism BL200C: Quick attach mechanism Loader Model TX47 BL200C Loader Lift Height TX47: 105.6 in BL200C: 106.6 in Loader Lift Capacity (Full Height) TX47: 2,152 lb (at pivot pin) BL200C: 2,701 lb (at pivot pin) Loader Breakout Force TX47: 3,198 lb (at pivot pin, ground level) BL200C: 3,660 lb (at pivot pin, ground level) ▶ WarrantyWarranty Length & Coverage Basic 24 months or 2,000 hours, parts and labor; non-commercial: powertrain 72 months or 3,000 hours; rental and commercial: powertrain 36 months or 2,000 hours; loaders and backhoes 12 months Basic 2 years or 2,000 hours; powertrain 3,000 hours maximum, parts and labor; loaders and backhoes 12 months ▶ ITC Company AccessoriesAccessories that fit
