▶ EngineEngine Manufacturer Yanmar Mahindra Engine Model 4TNV88C-XKITL DH45 Engine Type 4-cylinder, liquid-cooled diesel Four-stroke, naturally aspirated, direct injection, water cooled diesel No. of Cylinders 4 4 Displacement 133.6 in³ 166.2 in³ Rated Engine Speed Not Published 2300 rpm Engine Power (Gross) 46 hp 45 hp PTO Power 35.5 hp 38 hp Engine Emissions Constraints Not Published Tier 4 Cooling System Type Liquid cooled Water-cooled Air Cleaner Dual air cleaner element Not Published Fuel System Not Published Direct injection Alternator Not Published 55 A ▶ HydraulicsPump Type Not Published Not Published Implement Flow 9.3 gpm 8.71 gpm Steering Flow 5.3 gpm 4.62 gpm Total Hydraulic Flow 14.6 gpm 13.3 gpm Overall Hydraulic Pump Flow 14.6 gpm 13.3 gpm Hydraulic System Type Not Published Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves 1 1 No. of Optional Remote Valves 2 1 ▶ Fluid CapacityFuel Tank Capacity 13.2 gal 17.1 gal Coolant Capacity 6.3 qt Not Published Crankcase Capacity 5.1 qt Not Published Transmission / Hydraulic System Capacity 9.0 gal Not Published Front Axle Fluid Capacity 2.4 gal Not Published ▶ PTO & HitchPTO Type Independent Independent PTO Rear 540/540E rpm 540 rpm @ 2300 engine rpm; 540E rpm @ 1725 engine rpm Mid-PTO Availability Not Published Not Published Category, 3-Point Hitch Category I & II CAT I & II with telescopic stabilizers & flex links Hitch Lift Capacity 3,190 lb Not Published Hitch Lift Capacity (at 24”) 2,750 lb 3748 lb Lift Control Type Not Published Position control ▶ Transmission & DrivetrainTransmission Type Synchronized shuttle shift Full synchromesh with forward/reverse synchro shuttle & constant mesh range No. of Speeds F8-R8 12F / 12R Max Travel Speed (Forward) 17.7 mph 17.9 mph Max Travel Speed (Reverse) Not Published Not Published Clutch Dry Single Dual dry with cerametallic lining Differential Lock & Limited Slip Options Differential lock (foot pedal) Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Power steering Hydrostatic power steering with tilt steering wheel Brakes Not Published Fully-enclosed, 7-in diameter, dry disc Seat Suspension & Adjustability Suspension seat Adjustable seat with contoured cushions, armrests and a soft-coil suspension Front Axle Type Selectable 2WD/4WD engagement Not Published Front Axle Rating Not Published Not Published Drawbar Capacity Not Published Not Published ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 133.6 in (with 3PH and R4 tires) 136.6 in Overall Width 70.9 in (with R4 tires) 74.8 in Wheelbase 74.8 in 77.9 in Ground Clearance 15.5 in 15.2 in Min. Turn Radius without Brakes 138 in 10.8 ft Height to Top of ROPS 98.0 in (with R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 3,916 lb 5390 lb Weight with ROPS and Loader 5,129 lb 6,690 lb Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural or R4 Industrial R1 Agricultural - Front 8.0 - 16.0 9.5 x 20 R1 Agricultural - Rear 14.9 - 24.0 14.9 x 28 R3 Turf - Front 27.0 - 10.5 Not Published R3 Turf - Rear 44 x 18 - 20.0 Not Published R4 Industrial - Front 10.0 - 16.5 10.5/80 x 18 R4 Industrial - Rear 17.5L - 24.0 16.9 x 24 ▶ Loader & AttachmentsQuick Attach Loader System YL605: Skid steer quick attach Skid-steer style quick-attach coupler Loader Model YL605 5155-4L (front loader); 65B (rear backhoe) Loader Lift Height YL605: 113.0 in 5155-4L: 122 in Loader Lift Capacity (Full Height) YL605: 2,500 lb 5155-4L: 3,100 lb Loader Breakout Force YL605: 3,047 lb (19.7 in forward of pivot pin) 5155-4L: 5,200 lb ▶ WarrantyWarranty Length & Coverage 10-year limited powertrain warranty or 3,000 hours (whichever comes first) 5-year limited powertrain warranty
