▶ EngineEngine Manufacturer YANMAR Yanmar Engine Model 3TNV88C 3TNV88C-KJPT Engine Type 3-cylinder, naturally aspirated diesel 4-cycle, inline, water-cooled diesel, naturally aspirated No. of Cylinders 3 3 Displacement 100.1 in³ 100.1 in³ Rated Engine Speed 2800 rpm 2800 rpm Engine Power (Gross) 34.2 hp 34.2 hp PTO Power 27 hp 30.4 hp Engine Emissions Constraints Tier 4 Tier 4 Cooling System Type Liquid cooled Liquid Air Cleaner Dual stage cyclonic (resin 5.5 in.) Dual element Fuel System Common rail direct injection Direct injection Alternator 40 A, 12 V 55 A, 12 V ▶ HydraulicsPump Type Not Published Two single-section external gear pumps, one each side of engine timing-gear cover Implement Flow 7.1 gpm 4.8 gpm Steering Flow 4.1 gpm 3.6 gpm Total Hydraulic Flow 11.2 gpm (7.1 + 4.1, computed) Not Published Overall Hydraulic Pump Flow 11.2 gpm (7.1 + 4.1, computed) 10.3 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published No. of Standard Remote Valves Not Published Not Published No. of Optional Remote Valves Not Published Up to two (optional) ▶ Fluid CapacityFuel Tank Capacity 7.4 gal 10.0 gal Coolant Capacity 4.8 qt 1.2 gal Crankcase Capacity 4.6 qt 1.1 gal Transmission / Hydraulic System Capacity 8.2 gal 9.2 gal Front Axle Fluid Capacity 2.4 gal 1.0 gal ▶ PTO & HitchPTO Type Independent (electro-hydraulic) Mechanical control; transmission clutch; wet disk brake (mid/rear PTO) PTO Rear 540 rpm 540 rpm at 2800 rpm engine (rated) Mid-PTO Availability Standard Not Published Category, 3-Point Hitch Category I Category I Hitch Lift Capacity 2,205 lb Not Published Hitch Lift Capacity (at 24”) 1,764 lb 2081.2 lb Lift Control Type Position control Position control ▶ Transmission & DrivetrainTransmission Type Hydrostatic (Dual Touch Pedal) 8F/8R synchromesh shuttle shift gear transmission No. of Speeds Unlimited (hydrostatic); 3 ranges 8F/8R Max Travel Speed (Forward) 11.7 mph (with R4 tires) Not Published Max Travel Speed (Reverse) 8.2 mph (with R4 tires) Not Published Clutch N/A (hydrostatic) Single dry traction clutch Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Differential lock: Yes; limited slip: Not Published ▶ Chassis, Steering & ControlsFrame Type Not Published Not Published Steering Fully hydraulic power steering Power steering Brakes Wet disc Wet disk Seat Suspension & Adjustability Not Published Not Published Front Axle Type 2WD/4WD selectable engagement MFWD (4WD) Front Axle Rating Not Published 1940 lb Drawbar Capacity Not Published 1102 lb ▶ Dimensions & ManeuverabilityOverall Length with 3-Point Hitch 116.9 in 111.2 in Overall Width 58.3 in (with R4 tires) 57.3 in Wheelbase 65 in 62.6 in Ground Clearance 10.8 in (with R4 tires) 13.0 in Min. Turn Radius without Brakes Not Published 6.9 ft (with brakes) (with brake applied) Height to Top of ROPS 89.0 in (with R4 tires) Not Published Height to Top of ROPS (folded) Not Published Not Published Height to Top of Cab Model Not Published Not Published ▶ WeightTractor Weight (Base) 2,558 lb (with ROPS, R4 tires, full fluid) 3166 lb Weight with ROPS and Loader 3,471 lb Not Published Weight with Cab and Loader Not Published Not Published ▶ Tire OptionsTire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Bar, R3 Turf, R4 Industrial R1 Agricultural - Front 6-14 7-14 R1 Agricultural - Rear 9.5-22 11.2-24 R3 Turf - Front 25x8.5-14 27X8.5-15 R3 Turf - Rear 13.6x16 41X14-20 R4 Industrial - Front 25x8.5-14 25X8.5-14 R4 Industrial - Rear 15-19.6 15-19.5 ▶ Loader & AttachmentsQuick Attach Loader System YL310: Skid steer style bucket attachment Quick-change attachment carrier Loader Model YL310 D160 Loader Lift Height YL310: 84 in (to bucket pivot pin) 84.0 in Loader Lift Capacity (Full Height) YL310: 1,300 lb at pivot pins 1,186 lb Loader Breakout Force YL310: 2,105 lb at pivot pins 1,704 lb ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-year/2,000-hour powertrain; 2-year/2,000-hour basic (full machine)
