▶ EnginePTO Power 27 hp 25.7 hp Alternator 55 A, 12 V 70 A, 12 V Air Cleaner Dual stage cyclonic (resin 5.5 in.) Dual element dry air cleaner Engine Type 3-cylinder, naturally aspirated diesel Turbocharged diesel Fuel System Common rail direct injection High pressure common rail (ECU controlled timing) Displacement 100.2 in³ 0.1 in³ No. of Cylinders 3 3 Rated Engine Speed 2800 rpm 2600 rpm Cooling System Type Liquid cooled Pressurized liquid with recirculating bypass Engine Manufacturer YANMAR LS Mtron Engine Power (Gross) 34.2 hp 35 hp Engine Emissions Constraints Tier 4 Tier 4B Final ▶ WeightWeight with ROPS and Loader Not Applicable HST: 2,400 lb; Gear: 2,390 lb (with ROPS / less tires) Weight with Cab and Loader 3,823 lb Not Applicable ▶ WarrantyWarranty Length & Coverage Tractor: 24 months or 2,000 hours; Powertrain: 10 years or 3,000 hours; Attachments: 1-year limited warranty 6-year limited warranty (2-year bumper-to-bumper + 4-year powertrain) ▶ HydraulicsPump Type Not Published Gear Steering Flow 4.1 gpm 4.8 gpm Implement Flow 7.1 gpm 8.2 gpm Total Hydraulic Flow 11.2 gpm 13.0 gpm Hydraulic System Type Open center Open center Rear Remote Hydraulic Flow Not Published Not Published Overall Hydraulic Pump Flow 11.2 gpm 13.0 gpm No. of Optional Remote Valves Not Published 1 or 2 No. of Standard Remote Valves Not Published 0 ▶ PTO & HitchPTO Rear 540 rpm 540 rpm (6-spline) PTO Type Independent (electro-hydraulic) Independent Lift Control Type Position control Position control Hitch Lift Capacity 2,205 lb 1,808 lb Mid-PTO Availability Standard Optional Category, 3-Point Hitch Category I Category I Hitch Lift Capacity (at 24”) 1,764 lb 1,433 lb ▶ Tire OptionsR3 Turf - Rear 13.6x16 41X14.00-20 R3 Turf - Front 25x8.5-14 25X8.50-14 Tire Size & Options R1 Agricultural; R3 Turf; R4 Industrial R1 Agricultural, R3 Turf, R4 Industrial R4 Industrial - Rear 15-19.6 43X16-20 R4 Industrial - Front 25x8.5-14 25X8.50-14 R1 Agricultural - Rear 9.5-22 11.2-24 R1 Agricultural - Front 6.0-14 7.0-14 ▶ Fluid CapacityCoolant Capacity Not Published 7.5 qt Crankcase Capacity Not Published 5.8 qt Fuel Tank Capacity 7.4 gal 7.4 gal Front Axle Fluid Capacity Not Published 6.9 qt Transmission / Hydraulic System Capacity Not Published 8.5 gal ▶ Loader & AttachmentsLoader Lift Height 84 in 91.5 in (to bucket pivot pin) Loader Breakout Force 2,105 lb 2,700 lb (bucket pivot pin) Quick Attach Loader System YL310: Skid steer style bucket attachment 140TL: Quick Mount (easy attach/remove); optional skid steer quick attach plates Loader Lift Capacity (Full Height) 1,300 lb 1,500 lb (bucket pivot pin, max height) ▶ Transmission & DrivetrainClutch N/A (hydrostatic) HST: Not Applicable; Gear: Dry disc, 9.4 in No. of Speeds Unlimited (hydrostatic); 3 ranges HST: Infinite (3-range); Gear: 12F/12R Transmission Type Hydrostatic (Dual Touch Pedal) HST: 3-range hydrostatic / dual pedal; Gear: 12x12 synchronized shuttle Max Travel Speed (Forward) 11.7 mph (with R4 tires) HST: 14.96 mph; Gear: 14.33 mph Max Travel Speed (Reverse) 8.2 mph (with R4 tires) HST: 14.96 mph; Gear: 13.63 mph Differential Lock & Limited Slip Options Rear differential lock (foot pedal engagement) Mechanical rear differential lock ▶ Chassis, Steering & ControlsBrakes Wet disc Wet disc Steering Fully hydraulic power steering Power steering Frame Type Not Published Not Published Front Axle Type Selectable 4WD (2WD/4WD engagement) 4WD (FWD) Drawbar Capacity Not Published Not Published Front Axle Rating Not Published Not Published Seat Suspension & Adjustability Not Published Not Published ▶ Dimensions & ManeuverabilityWheelbase 65 in 69 in Overall Width 58.3 in (with R4 tires) 54 in Ground Clearance 10.8 in (with R4 tires) 13 in Height to Top of ROPS Not Applicable 89 in Height to Top of Cab Model 83.6 in (with R4 tires) Not Applicable Height to Top of ROPS (folded) Not Published Not Published Min. Turn Radius without Brakes Not Published Not Published Overall Length with 3-Point Hitch 116.9 in 134 in
