Non-Commercial Home & Residential Use - Basic Standard Limited: 24 months or 1500 hours; Limited Powertrain: 72 months or 2000 hours. Commercial Use - Basic Standard Limited: 24 months or 1500 hours.
Pump Type
Not Published
Hydrostatic transmission
Steering Flow
4.5 gpm
1.0 gpm
Implement Flow
6.9 gpm
6.2 gpm (23.5 l/min.)
Total Hydraulic Flow
11.4 gpm
6.2 gpm
Hydraulic System Type
Not Published
Open center tandem pump gear type
Rear Remote Hydraulic Flow
Not Published
Not Published
Overall Hydraulic Pump Flow
11.4 gpm
6.2 gpm
No. of Optional Remote Valves
2 pairs (optional)
2 (optional; ISO 7241-1 series A or B)
No. of Standard Remote Valves
Not Published
2 valves
System Operating Pressure
—
12.3 MPa to 12.8 MPa
PTO Rear
540 rpm
STD 540 rpm
PTO Type
Live
Live independent PTO (with hydraulic clutch)
Lift Control Type
Hydraulic position control system
Quarter-inching valve
Hitch Lift Capacity
1,631 lb
1,213 lbs.
Mid-PTO Availability
1,976 rpm (optional)
STD (2500rpm)
Category, 3-Point Hitch
Category 1
SAE Category 1
Hitch Lift Capacity (at 24”)
1,631 lb
680 lb
R3 Turf - Rear
Not Published
26×12-12
R3 Turf - Front
Not Published
18×8.5-10
Tire Size & Options
Not Published
Front Turf/Industrial: 18×8.5-10; Rear Turf/Industrial: 26×12-12; Bar tire N/A
R4 Industrial - Rear
Not Published
26×12-12
R4 Industrial - Front
Not Published
18×8.5-10
R1 Agricultural - Rear
Not Published
Not Applicable
R1 Agricultural - Front
Not Published
Not Applicable
Coolant Capacity
Not Published
0.8 gal (3.3 U.S.qts.)
Crankcase Capacity
Not Published
0.9 gal (3.4 U.S.qts.)
Fuel Tank Capacity
9.0 gal
6.6 gal (6.6 U.S.gals.)
Front Axle Fluid Capacity
Rear (Std); Mid (optional)
Not Published
Transmission / Hydraulic System Capacity
Not Published
2.98 U.S. gals.
Loader Lift Height
Not Published
71.0 in
Loader Breakout Force
Not Published
6258 N (1407 lbs) [LA340] / 5719 N (1286 lbs) [LA340S]
